Product Details
Introduction
The combination of its fast print speeds, high reliability and economical operation, make this printer a must-have for small retail and speciality stores, hospitality venues and grocery stores.
Printing
Colour
No
Maximum resolution
203 x 203 DPI
Print speed
250 mm/sec
Character size
1.25 x 3 mm
Character density
22.6 cpi
Printing characters
Graphic
Print technology
Thermal
Type
POS printer
Paper handling
Printing media thickness
53 - 75 µm
Maximum roll diameter
8.3 cm
Supported paper width
80 mm
Ports & interfaces
USB port
Yes
USB 2.0 ports quantity
1
USB connector
USB Type-B
Serial interface
Yes
Serial interface type
RS-232
Connectivity technology
Wired
Optional connectivity
Ethernet, Wireless LAN
Network
Ethernet LAN
No
Wi-Fi
No
Features
Built-in barcodes
CODABAR (NW-7), Code 39, Code 93, EAN13, EAN8, GS1 DataBar, GS1-128, ITF, UPC-A, UPC-E
Mean time between failures (MTBF)
360000 h
Cutter
Yes
Autocutter durability
2 million cuts
Print head life
150 km
Wall mountable
Yes
Receive buffer
4 KB
Built-in sensors details
Paper End Sensor, Paper Near End Sensor
Country of origin
Philippines
Design
Product colour
Black
Power
Power source type
DC
Power consumption (printing)
27.2 W
AC input voltage
100 - 230 V
AC input frequency
50/60 Hz
DC output voltage
24 V
Power consumption (standby)
0.96 W
Operational conditions
Operating temperature (T-T)
5 - 45 °C
Storage temperature (T-T)
-10 - 50 °C
Operating relative humidity (H-H)
10 - 90%
Storage relative humidity (H-H)
10 - 90%
System requirements
Windows operating systems supported
Yes
Mobile operating systems supported
Android, iOS
Weight & dimensions
Width
140 mm
Depth
199 mm
Height
146 mm
Weight
1.7 kg
Packaging data
Cables included
AC
Quantity per pack
1 pc(s)
Package width
195 mm
Package depth
235 mm
Package height
280 mm
Package weight
2.65 kg
Packaging content
AC adapter included
Yes
Technical details
Compliance certificates
Federal Communications Commission (FCC), ICES
Safety warning
UL62368-1, CAN/CSA C22.2 No.62368-1
Box contents
AC adapter, C1, Main unit, Paper roll spacer, Cable cover, UK AC cable
Other features
Mean cycles between failures (MCBF)
60000000
Logistics data
Products per pallet
112 pc(s)
Products per pallet layer
16 pc(s)
Pallet gross width
80 cm
Pallet gross length
120 cm
Pallet gross height
2.11 m
Products per pallet (UK)
168 pc(s)
Products per pallet layer (UK)
24 pc(s)
Pallet length (UK)
120 cm
Pallet height (UK)
2.11 m
Information
| Part Number: | C31CL47101A0 |
