Introduction
The HPE Aruba Networking CX 6200 Switch Series is a next-gen family of stackable access switches ideal for enterprise branch offices, campuses, and SMB networks. With a cloud-centric design that combines a fully programmable OS with the HPE Aruba Networking CX Network Analytics Engine, this switch family extends industry-leading deployment, monitoring, and troubleshooting to the access layer. Make your network ready for tomorrow’s unpredictable demands with a powerful Gen7 ASIC architecture to deliver fast, non-blocking performance. HPE Aruba Networking Virtual Stacking Framework (VSF) allows for stacking of up to 8 switches, providing scale and simplified management. This series includes fixed (CX 6200F) and modular (CX 6200M) switches with built-in high speed uplinks and up to 1440W of PoE to support IoT devices such as security cameras and wireless APs.
What is new supporting point:
Enterprise-class connectivity with support for ACLs, robust QoS, and common protocols such as static and Access OSPF routing.
Up to 384 ports of scalability with 8-member VSF stacking. 24 and 48-port fixed and modular switches can stack together with easy to deploy through the CX Mobile app.
Models include modular switches with 1/10 GbE uplinks, LRM, and MACSec 256, fixed switches with either 1/10 GbE SFP+ or 1 GbE SFP uplinks, and options that support 30W to 60W of PoE per port.
Intelligent monitoring and visibility via HPE Aruba Networking CX Network Analytics Engine. HPE Aruba Networking Switch Multi-Edit Software support for automation, configuration and verification.
Dynamic Segmentation enables secure access for users and IoT.
Flexible, modular switch models support hot-swappable, redundant power supplies and fans for enhanced resiliency.
Management features
Switch type
Managed
Switch layer
L3
Quality of Service (QoS) support
Yes
Switch type
Managed
Switch layer
L3
Quality of Service (QoS) support
Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity
48
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
SFP+ module slots quantity
4
Console port
RJ-45/USB Type-C
Basic switching RJ-45 Ethernet ports quantity
48
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
SFP+ module slots quantity
4
Console port
RJ-45/USB Type-C
Network
Networking standards
IEEE 802.1AX, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ak, IEEE 802.1p, IEEE 802.1s, IEEE 802.1t, IEEE 802.1v, IEEE 802.1w, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3x, IEEE 802.3z
10G support
Yes
Port mirroring
Yes
Flow control support
Yes
Link aggregation
Yes
Auto MDI/MDI-X
Yes
Spanning tree protocol
Yes
VLAN support
Yes
Networking standards
IEEE 802.1AX, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ak, IEEE 802.1p, IEEE 802.1s, IEEE 802.1t, IEEE 802.1v, IEEE 802.1w, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3x, IEEE 802.3z
10G support
Yes
Port mirroring
Yes
Flow control support
Yes
Link aggregation
Yes
Auto MDI/MDI-X
Yes
Spanning tree protocol
Yes
VLAN support
Yes
Optical fiber
Transmission distance (max)
10 km
Transmission distance (max)
10 km
Data transmission
Switching capacity
176 Gbit/s
Throughput
130.9 Mpps
MAC address table
32768 entries
Latency (1 Gbps)
2.28 µs
Latency (10 Gbps)
1.46 µs
Packet buffer memory
8 MB
MAC address table
32768 entries
Latency (1 Gbps)
2.28 µs
Latency (10 Gbps)
1.46 µs
Packet buffer memory
8 MB
Security
Access Control List (ACL)
Yes
IGMP snooping
Yes
Authentication
MAC-based authentication, Web-based authentication
Authentication type
RADIUS, TACACS+
Access Control List (ACL)
Yes
IGMP snooping
Yes
Authentication
MAC-based authentication
Authentication type
RADIUS, TACACS+
Multicast features
Multicast support
Yes
Multicast support
Yes
Design
Rack mounting
Yes
Stackable
Yes
Form factor
1U
Rack mounting
Yes
Form factor
1U
Performance
Physical stacking (units)
8
Built-in processor
Yes
Processor model
ARM Cortex-A72
Processor frequency
1800 MHz
Memory type
DDR4-SDRAM
Internal memory
8000 MB
Flash memory
16384 MB
Processor model
ARM Cortex-A72
Flash memory
16384 MB
Power
Power source
AC
Power supply included
Yes
Redundant power supply (RPS) support
No
AC input voltage
200 - 240 V
AC input frequency
50 - 60 Hz
Power consumption (max)
76 W
Power supply note
Fixed power supply Up to 370W of Class 4 PoE Power
Power source
AC
Power supply included
Yes
Redundant power supply (RPS) support
No
AC input voltage
200 - 240 V
AC input frequency
50 - 60 Hz
Power consumption (max)
76 W
Power consumption note
76W at 230 VAC
Power over Ethernet (PoE)
Power over Ethernet (PoE)
Yes
Total Power over Ethernet (PoE) budget
370 W
Operational conditions
Operating temperature (T-T)
0 - 45 °C
Storage temperature (T-T)
-40 - 70 °C
Operating relative humidity (H-H)
5 - 95%
Storage relative humidity (H-H)
5 - 95%
Storage temperature (T-T)
-40 - 70 °C
Operating relative humidity (H-H)
5 - 95%
Storage relative humidity (H-H)
5 - 95%
Weight & dimensions
Width
43.9 mm
Depth
442 mm
Height
327 mm
Weight
5.1 kg
Other features
Latency
1 Gbps: 2.28 µSec 10 Gbps: 1.46 µSec
Memory and processor
CPU: Quad-core Arm Cortex-A72 at 1.8 GHz Memory: 8 GB DDR4 Flash: 16 GB eMMC
I/O ports
48 x 10/100/1000BASE-T Class 4 PoE ports, supporting up to 30W per port 4 x 100M/1/10G SFP+ ports Supports PoE standards IEEE 802.3af, 802.3at 1 x USB-C console port 1 x USB Type-A host port 1 x OOBM 1 x RJ-45 console port
Performance management
Management flexibility with support for HPE Aruba Networking Central, easy-to-use Web GUI, CLI, and HPE Aruba Networking Switch Multi-Edit Software
Weight (imperial)
5.1 kg (11.2 lbs)
Dimensions (W x D x H) (imperial)
43.9 x 442 x 327.7 mm (1.73 x 17.4 x 12.9")
Fan
Fixed fans
