Introduction
Aruba Instant On 1960 Switches are advanced, smart-managed, fixed configuration Gigabit stackable switches designed for small and growing businesses that are easy to deploy and affordable. These switches are designed to scale as business grows, making adding more employees, devices and applications simple. Aruba Instant On 1960 switches are made to handle today's bandwidth-heavy applications like voice and video conferencing, enabling consistent connectivity to improve user experience and application performance. These switches come with flexible management option: local web GUI or Instant On mobile app and cloud-based web portal.
Features
High-level Gigabit with 10GbE Networking for Advanced Small Businesses
- Each model of the Aruba Instant On 1960 Switch Series includes four 10GbE connections to connect to servers, network storage devices, or to other switches.
- Two connections of 10GBASE-T deliver 10GbE over copper Category 6a cabling for simple, affordable, high-bandwidth connections to a maximum distance of 100 meters.
- With PoE models, up to 30W PoE power delivery is available for Class 4 PoE devices like access points, surveillance cameras and VoIP phones, and up to 60W PoE power delivery is available for Class 6 PoE devices like pan-tilt zoom cameras and video-enabled IP-phones.
Simplify Network Deployment and Management for Small Organizations
- The Aruba Instant On 1960 Switch series offers a complete portfolio of choices for increased small business flexibility. It consists of five models including two (2) 24-port and two (2) 48-port models in PoE and non-PoE configurations, and a 12 port 10-Gigabit aggregation switch.
- The 24-port and 48-port PoE models come with a power budget of 370W and 600W respectively to support the latest PoE-powered IoT devices.
- The Aruba Instant On 1960 Switch series can be deployed using two management modes - Instant On cloud-management (access via mobile app and/or web portal) and the local web GUI.
- Each switch has a pull-out tag, known as a luggage tag, on the front panel of the switch.
- The tag includes a QR code that includes switch ID information (SKU number, SKU name, serial number, and MAC address) for easy switch onboarding through Instant On mobile app.
Ease of Use with Cloud-Managed Stacking
- The Aruba Instant On mobile app and cloud-based web portal make cloud-managed stacking easy - just follow the recommendations to stack up to four (4) Aruba Instant On 1960 switches and manage as a single entity.
- The Aruba Instant On mobile app automatically detects members, making multiple stack members easy to setup and manage remotely.
- Automated configurations and streamlined workflows allow users to manage all stack members through one single dashboard without the need for device reboot.
Robust Security to Protect Your Network
- The Aruba Instant On 1960 Switch Series lets you use VLANs and Access Control Lists to set bounds on what data can be seen by which users.
- Leverage 802.1X with a RADIUS server to ensure only known and authorized users can access your network.
- Supports Automatic denial-of-service (DOS) monitors and protects the network against malicious attacks.
Management features
System event log
Yes
Switch type
Managed
Switch layer
L2+
Quality of Service (QoS) support
Yes
Web-based management
Yes
Cloud-managed
Yes
System event log
Yes
Switch type
Managed
Switch layer
L2+
Quality of Service (QoS) support
Y
Web-based management
Y
Cloud-managed
Y
Data transmission
Jumbo frames
9216
Packet buffer memory
1.5 MB
MAC address table
16000 entries
Latency (10-100 Mbps)
7.4 µs
Latency (1 Gbps)
4.2 µs
Latency (10 Gbps)
1.1 µs
Jumbo frames support
Yes
Jumbo frames
9216
Switching capacity
320 Gbit/s
Throughput
238 Mpps
MAC address table
16000 entries
Latency (10-100 Mbps)
7.4 µs
Latency (1 Gbps)
4.2 µs
Latency (10 Gbps)
1.1 µs
Jumbo frames support
Y
Performance
Internal memory
1024 MB
Flash memory
512 MB
Processor model
ARM Cortex-A9
Processor frequency
2000 MHz
Memory type
DDR3-SDRAM
Physical stacking (units)
4
Built-in processor
Y
Processor model
ARM Cortex-A9
Processor frequency
2000 MHz
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity
12
Basic switching RJ-45 Ethernet ports type
10G Ethernet (100/1000/10000)
SFP+ module slots quantity
4
Basic switching RJ-45 Ethernet ports quantity
12
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
SFP+ module slots quantity
4
Operational conditions
Operating altitude
0 - 3000 m
Storage temperature (T-T)
-40 - 70 °C
Operating relative humidity (H-H)
15 - 95%
Storage relative humidity (H-H)
15 - 90%
Operating altitude
0 - 3000 m
Operating temperature (T-T)
0 - 40 °C
Storage temperature (T-T)
-40 - 70 °C
Operating relative humidity (H-H)
15 - 95%
Storage relative humidity (H-H)
15 - 90%
Network
Networking standards
IEEE 802.1x
10G support
Yes
Port mirroring
Yes
Full duplex
Yes
Flow control support
Yes
Link aggregation
Yes
Rate limiting
Yes
Auto MDI/MDI-X
Yes
Spanning tree protocol
Yes
Auto-sensing
Yes
VLAN support
Yes
Networking standards
IEEE 802.1AX,IEEE 802.1D,IEEE 802.1Q,IEEE 802.1ab,IEEE 802.1p,IEEE 802.1s,IEEE 802.1w,IEEE 802.1x,IEEE 802.3ab,IEEE 802.3ad,IEEE 802.3az,IEEE 802.3u,IEEE 802.3z
10G support
Y
Port mirroring
Y
Full duplex
Y
Flow control support
Y
Link aggregation
Y
Rate limiting
Y
Auto MDI/MDI-X
Y
Spanning tree protocol
Y
Auto-sensing
Y
VLAN support
Y
Security
DHCP features
DHCP snooping
Access Control List (ACL)
Yes
IGMP snooping
Yes
SSH/SSL support
Yes
Authentication
Port-based authentication
Authentication type
RADIUS
DHCP features
DHCP snooping
Access Control List (ACL)
Y
IGMP snooping
Y
SSH/SSL support
Y
Authentication
Port-based authentication
Authentication type
RADIUS
Multicast features
Multicast support
Yes
Multicast support
Y
Protocols
IPv4 & IPv6 features
IPv4/IPv6 access-control list (ACL)
IPv4 FIB entries
512
IPv6 FIB entries
512
IPv4 & IPv6 features
IPv4/IPv6 access-control list (ACL)
IPv4 FIB entries
512
IPv6 FIB entries
512
Design
Rack mounting
Yes
Form factor
1U
Product colour
White
Rack mounting
Y
Stackable
Y
Form factor
1U
Product colour
White
Power
Power source
AC
Power supply included
Yes
AC input frequency
50 - 60 Hz
Power consumption note
Maximum: 100-127V: 130W 200-220V: 160W Idle: 100-127V: 60W 200-220V: 80W
Power source
AC
Power supply included
Y
AC input voltage
100 - 240 V
AC input frequency
50/60 Hz
Power consumption (max)
160 W
Power over Ethernet (PoE)
Power over Ethernet (PoE)
No
Power over Ethernet (PoE)
N
Other features
Memory and processor
Single-Core ARM v7 Cortex-A9 @800 MHz; 1 GB DDR3; 512 MB NAND flash; Packet buffer size: 1.5 MB
I/O ports
12 RJ-45 autosensing 1000/10 GBASE-T ports (IEEE 802.3ab Type 1000 BASE-T, IEEE 802.an 10 GBASE-T); Duplex: 100 BASE-TX: half or full; 1000 BASE-T: full only 10 GBASE-T: full only 4 SFP+ 10GbE ports
Performance management
HPE Networking Instant On Cloud; Web browser; SNMP Manager
Weight (imperial)
4.35 kg (9.6 lbs)
Logistics data
Harmonized System (HS) code
85176990
Harmonized System (HS) code
85176990
Weight & dimensions
Width
442.5 mm
Depth
350.5 mm
Height
44 mm
Weight
4.3 kg
