Introduction
The HPE Networking Instant On Access Points AP22D is an SMB-focused Wi-Fi Certified 6 access point that provides reliable wired and wireless connectivity over a 2.5GbE uplink port with a minimal device footprint. This access point can reduce device clutter while powering downlink devices such as IP Phones or receipt printers with 2x 15W of PoE(802.3af) and supporting 75+ wireless devices over 802.11ax Wi-Fi 6 with an aggregate wireless throughput of 1.7Gbps.
Easily manage the Instant On AP22D with the Instant On mobile app or portal to create guest and employee networks, govern access control lists, and set POE schedules to customize power use. Make the most of your limited space in your small business by mounting the Instant On AP22D to a desk or wall with included mounting kits.
Features
MIMO type
Multi User MIMO
2.4 GHz
Yes
5 GHz
Yes
6 GHz
No
Maximum data transfer rate
1200 Mbit/s
Maximum data transfer rate (2.4 GHz)
574 Mbit/s
Maximum data transfer rate (5 GHz)
1200 Mbit/s
Ethernet LAN data rates
1000,2500 Mbit/s
Networking standards
IEEE 802.11ax, IEEE 802.3at, IEEE 802.3bt
Cabling technology
10/100/1000Base-T(X)
Number of users
75 user(s)
MIMO
Yes
Design
Reset button
Yes
Placement
Desk, Wall
Product colour
White
Cable lock slot
Yes
Cable lock slot type
Kensington
Security
Security algorithms
OWE, WPA2, WPA3
Ports & interfaces
Ethernet LAN (RJ-45) ports
5
USB 2.0 ports quantity
1
DC-in jack
Yes
Power
Power over Ethernet (PoE)
Yes
DC voltage range
48 V
Power consumption (typical)
50 W
Power consumption (max)
51 W
Power consumption (typical)
50 W
Antenna
Antenna type
Internal
Antenna direction type
Omni-directional
Antennas quantity
2
Antenna gain level (max)
5.4 dBi
Weight & dimensions
Width
86 mm
Depth
47 mm
Height
150 mm
Weight
360 g
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Certificates
Other features
I/O ports
1x 2.5 GbE Base-T PoE Class 4/6 uplink 2x 1 GbE Base-T PoE Class 3 downlink 2x 1 GbE Base-T downlink DC power connector LED status indicators Reset/LED control button Kensington security slot
Mounting
Gang wall box-mount kit or Desk-mount kit
