Product Details
Introduction
.
Processor
Processor model
6530P
Processor manufacturer
Intel
Processor base frequency
2.3 GHz
Processor family
Intel® Xeon®
Processor cores
32
Processor socket
LGA 4710
Processor threads
64
Processor operating modes
64-bit
Processor boost frequency
3.7 GHz
Processor cache
144 MB
Processor cache type
L3
Thermal Design Power (TDP)
225 W
Processor socket
LGA 4710
Processor threads
64
Processor operating modes
64-bit
Processor boost frequency
3.7 GHz
Memory
Maximum internal memory supported by processor
4 TB
Memory types supported by processor
DDR5-SDRAM
Memory clock speeds supported by processor
6400 MHz
Memory channels
Octa-channel
ECC
Yes
Maximum internal memory supported by processor
4 TB
Memory types supported by processor
DDR5-SDRAM
Memory channels
Octa-channel
ECC
Yes
Graphics
On-board graphics card
No
Discrete graphics card
No
On-board graphics card model
Not available
Discrete graphics card model
Not available
On-board graphics card
No
Discrete graphics card
No
On-board graphics card model
Not available
Discrete graphics card model
Not available
Features
Execute Disable Bit
Yes
Maximum number of PCI Express lanes
88
PCI Express slots version
5.0
Scalability
2S
Execute Disable Bit
Yes
Maximum number of PCI Express lanes
88
PCI Express slots version
5.0
Scalability
2S
Processor special features
Intel® Hyper Threading Technology (Intel® HT Technology)
Yes
Intel® Turbo Boost Technology
2.0
Intel® AES New Instructions (Intel® AES-NI)
Yes
Intel Trusted Execution Technology
Yes
Intel® Speed Shift Technology
Yes
Intel® Transactional Synchronization Extensions
Yes
Intel® Total Memory Encryption
Yes
Intel® Control-flow Enforcement Technology (CET)
Yes
Intel® Crypto Acceleration
Yes
Intel® Platform Firmware Resilience Support
Yes
Intel® Trust Domain Extensions (Intel® TDX)
Yes
Intel VT-x with Extended Page Tables (EPT)
Yes
Intel® Secure Key
Yes
Intel QuickAssist Technology
Yes
Intel Software Guard Extensions (Intel SGX)
Yes
Intel 64
Yes
Intel Virtualization Technology (VT-x)
Yes
Intel Virtualization Technology for Directed I/O (VT-d)
Yes
Intel® Boot Guard
Yes
Intel® Deep Learning Boost (Intel® DL Boost) on CPU
Yes
Intel® Resource Director Technology (Intel® RDT)
Yes
Intel® Volume Management Device (VMD)
Yes
Intel® Run Sure Technology
Yes
Mode-based Execute Control (MBE)
Yes
Intel® Total Memory Encryption - Multi Key
Yes
Intel® QuickAssist Software Acceleration
Yes
Intel® Advanced Matrix Extensions (AMX)
Yes
Intel® Hyper Threading Technology (Intel® HT Technology)
Yes
Intel® Turbo Boost Technology
2.0
Intel® AES New Instructions (Intel® AES-NI)
Yes
Intel Trusted Execution Technology
Yes
Intel® Speed Shift Technology
Yes
Intel® Transactional Synchronization Extensions
Yes
Intel® Total Memory Encryption
Yes
Intel® Control-flow Enforcement Technology (CET)
Yes
Intel® Crypto Acceleration
Yes
Intel® Platform Firmware Resilience Support
Yes
Intel® Trust Domain Extensions (Intel® TDX)
Yes
Intel VT-x with Extended Page Tables (EPT)
Yes
Intel® Secure Key
Yes
Intel QuickAssist Technology
Yes
Intel Software Guard Extensions (Intel SGX)
Yes
Intel 64
Yes
Intel Virtualization Technology (VT-x)
Yes
Intel Virtualization Technology for Directed I/O (VT-d)
Yes
Intel® Boot Guard
Yes
Intel® Deep Learning Boost (Intel® DL Boost) on CPU
Yes
Intel® Resource Director Technology (Intel® RDT)
Yes
Intel® Volume Management Device (VMD)
Yes
Intel® Run Sure Technology
Yes
Mode-based Execute Control (MBE)
Yes
Intel® Total Memory Encryption - Multi Key
Yes
Intel® QuickAssist Software Acceleration
Yes
Intel® Advanced Matrix Extensions (AMX)
Yes
Information
| Part Number: | P74571-B21 |
