Introduction
Are you looking for a scalable, compute-dense solution for high-performance workloads such as VDI, EDA, or CAD?
The HPE ProLiant DL360 Gen11 server is a rack-optimized 1U dense solution that delivers exceptional compute performance, upgraded high-speed data transfer rate, and memory depth with 2P compute capability. Powered by 4th Gen Intel® Xeon® Scalable processors with up to 60 cores, increased memory bandwidth, up to 8 TB of memory, and high-speed PCIe Gen5 I/O, the HPE ProLiant DL360 Gen11 server is a perfect rack-optimized, 1U 2P, dense solution for general-purpose virtualization workloads that require increased compute density with built-in security and flexibility.
The silicon root of trust anchors the server firmware to an HPE-exclusive ASIC, creating an immutable fingerprint for the Secure Intel Processor that must be matched exactly before the server will boot. The HPE ProLiant DL360 Gen11 server is an excellent choice for EDA, CAD, and VDI.
Processor
Processor boost frequency
3.9 GHz
Processor cores
12
Configurable TDP-down
4.5 W
Bus type
OPI
Configurable TDP-down
4.5 W
Bus type
OPI
Processor manufacturer
Intel
Processor family
Intel Xeon Silver
Processor model
4410Y
Processor frequency
2 GHz
Processor boost frequency
3.9 GHz
Processor cores
12
Processor cache
30 MB
Number of processors installed
1
Processor cache type
L3
Memory
Maximum internal memory
8 TB
Internal memory
32 GB
Internal memory type
DDR5-SDRAM
Memory layout (slots x size)
1 x 32 GB
Maximum internal memory
8000 GB
Memory clock speed
4800 MHz
Storage
Number of HDDs supported
8
Supported HDD sizes
2.5"
SSD interface
PCI Express 4.0
Supported SSD sizes
2.5"
Number of SSDs supported
8
RAID support
Yes
Number of HDDs supported
8
Supported HDD sizes
2.5"
Supported SSD sizes
2.5"
Number of SSDs supported
8
RAID support
Y
Optical drive type
N
SSD interface
PCI Express 4.0
Supported RAID controllers
HPE MR408i-o Gen11 x8 Lanes 4GB Cache OCP SPDM Storage Controller
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
3
VGA (D-Sub) ports quantity
1
Ethernet LAN (RJ-45) ports
1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
3
VGA (D-Sub) ports quantity
1
Expansion slots
2-slots (x16 FH, x16 HH) as standard. Upgradeable to 3rd slot in HH (or remove Slot 2 bracket to be FH at Slot 3) in a 2nd processor configuration. And maximum 2 OCP 3.0 PCIe5 slots.
Expansion slots
PCI Express x16 slots
2
PCI Express x16 slots
2
Network
Ethernet LAN
Y
Ethernet interface type
Gigabit Ethernet
LAN controller
Broadcom BCM5719
Design
Processor special features
CPU configuration (max)
1
Intel Smart Response Technology version
1.00
Intel Stable Image Platform Program (SIPP) version
0.00
Intel Secure Key Technology version
1.00
Intel TSX-NI version
0.00
CPU configuration (max)
1
Intel Smart Response Technology version
1.00
Intel Stable Image Platform Program (SIPP) version
0.00
Intel Secure Key Technology version
1.00
Intel TSX-NI version
0.00
Performance
Trusted Platform Module (TPM)
Yes
Management platform
Included - HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download).
Power
Power supply
800 W
Number of main power supplies
1
Power supply type
1x HPE 800W Flex Slot Titanium Hot Plug Low Halogen Power Supply Kit
Weight & dimensions
Width
600 mm
Depth
990 mm
Height
241 mm
Weight
32.3 kg
Width
241 mm
Other features
Standard fans
5x Standard Fans
Dimensions (W x D x H) (imperial)
241 x 599.9 x 990.1 mm (9.49 x 23.6 x 39")
Storage drive type
None ship standard, 8 SFF supported
Security features
UEFI Secure Boot and Secure Start support. Intel Software Guard Extensions (SGX) support. Immutable Silicon Root of Trust. Optional Trusted Supply Chain, iLO Security modes, TPM, Chassis Intrusion detection and Bezel Locking kits. For full security features refer to the QuickSpecs.
Weight (imperial)
32.3 kg (71.3 lbs)
Number of processors supported
1
