Introduction
Are you a small office or small business with branch offices looking for a budget friendly server that can fit almost anywhere? The HPE ProLiant MicroServer Gen11 delivers an affordable, compact yet powerful entry level server that you can customize for on-premises or for hybrid cloud possibilities while still meeting the enterprise-class performance, security, reliability, and expandability standards of the rest of the HPE ProLiant enterprise class server portfolio.
With a mini tower design, place it flat or vertically or wall mounted, depending on customer environment. The latest Intel® Xeon® E and Pentium® processors supported to deliver compute performance, increased memory capacity, as well as security and remote management into the server with HPE iLO silicon root of trust. The affordable starting price makes the HPE ProLiant MicroServer Gen11 a good value that has the networking and performance capacity to grow with your business as your needs and budget change over time.
Features
Proven, yet Reimagined for the Data-Driven Edge
- HPE ProLiant MicroServer Gen11 is a powerful yet affordable server for your daily business workloads.
- With four 4400 MT/s HPE DDR5 UDIMMs, it offers 16, 32 GB. and up to 128 GB memory capacity support.
- Two PCIe expansion slots with the PCIe 5.0 support provide reliable scalability.
- Optional wall mount kit provides deployment flexibility.
Small, Quiet and Uniquely Designed Servers Bring the User Experience to a New Level
- HPE ProLiant MicroServer Gen11 features fast setup with a unique form factor that is compact and ideal for small spaces.
- Embrace remote management with optional HPE iLO6 integration.
Mini in Size yet still Powerful and Secure
- HPE ProLiant MicroServer Gen11 features iLO Silicon root of trust with server management to provide enhanced security, proven reliability and superb usability.
- Modern Intel Xeon E-2400 and Pentium Gold processors provide impressive performance.
- Offer enterprise-grade security with TPM 2.0 embedded.
Processor
Processor cores
4
Motherboard chipset
Intel C262
Processor cache type
Smart Cache
Processor manufacturer
Intel
Processor family
Intel Xeon E
Processor model
E-2414
Processor frequency
2.6 GHz
Processor cores
4
Processor cache
12 MB
Motherboard chipset
Intel C262
Number of processors installed
1
Storage
Total storage capacity
0 GB
Maximum storage capacity
16 TB
Total storage capacity
0 GB
HDD interface
SATA
Number of HDDs supported
4
Supported HDD sizes
3.5"
SSD interface
PCI Express 4.0
RAID support
Yes
RAID levels
0, 1, 5, 10
Hot-Plug support
No
SSD interface
PCI Express 4.0
Supported RAID controllers
Embedded Intel VROC SATA for HPE ProLiant Gen11
Maximum storage capacity
16 TB
HDD interface
SATA
Number of HDDs supported
4
Supported HDD sizes
3.5"
RAID support
Yes
RAID levels
0, 1, 5, 10
Hot-Plug support
No
Optical drive type
No
Memory
Memory slots
4x DIMM
ECC
Yes
Maximum internal memory
128 GB
Internal memory
16 GB
Internal memory type
DDR5-SDRAM
Memory slots
4x DIMM
ECC
Yes
Memory clock speed
4800 MHz
Memory layout (slots x size)
1 x 16 GB
Maximum internal memory
128 GB
Network
LAN controller
Broadcom BCM5719
LAN controller
Broadcom BCM5719
Ethernet LAN
Yes
Ethernet interface type
Gigabit Ethernet
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
4
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
2
VGA (D-Sub) ports quantity
1
DisplayPorts quantity
1
Expansion slots
2 PCIe, for detailed descriptions reference the QuickSpecs
Ethernet LAN (RJ-45) ports
4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
4
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
2
VGA (D-Sub) ports quantity
1
DisplayPorts quantity
1
Design
Redundant fans support
No
Chassis type
Ultra Micro Tower
Redundant fans support
No
Performance
Remote administration
iLO 6 ASIC
Management platform
HPE iLO Enablement Kit optional
Remote administration
iLO 6 ASIC
Trusted Platform Module (TPM)
Yes
Trusted Platform Module (TPM) version
2.0
Power
Number of main power supplies
1
Redundant power supply (RPS) support
No
Power supply input voltage
100 - 240 V
Power supply input frequency
50 - 60 Hz
Power supply type
1x 180W External Power Adapter, Non-Redundant Power Supply
Redundant power supply (RPS) support
No
Power supply
180 W
Power supply input voltage
100 - 240 V
Power supply input frequency
50 - 60 Hz
Software
Operating system installed
No
Compatible operating systems
Microsoft Windows Server 2022: Essentials, Standard, Datacenter
Red Hat Enterprise Linux (RHEL): 8.8, 9.2 (64 bit, includes KVM)
VMware vSphere: 8.0 U2
Canonical Ubuntu 20.04 & 22.04
Operating system installed
No
Compatible operating systems
Microsoft Windows Server 2022: Essentials, Standard, Datacenter
Red Hat Enterprise Linux (RHEL): 8.8, 9.2 (64 bit, includes KVM)
VMware vSphere: 8.0 U2
Canonical Ubuntu 20.04 & 22.04
Weight & dimensions
Width
154 mm
Width
377 mm
Depth
467 mm
Height
255.4 mm
Weight
7.97 kg
Other features
Standard fans
1x Standard Fan
Dimensions (W x D x H) (imperial)
153.9 x 261.1 x 249.4 mm (6.06 x 10.3 x 9.82")
Storage drive type
None ship standard, 4 LFF supported
Security features
Trusted Platform Module (TPM) 2.0
Weight (imperial)
7.97 kg (17.6 lbs)
Number of processors supported
1
