Product Details
Memory
Memory layout (slots x size)
2 x 32 GB
Internal memory
64 GB
Internal memory type
DDR5-SDRAM
Memory clock speed
5600 MHz
Storage
SSD interface
PCI Express 4.0
Supported RAID controllers
HPE MR416i-p Gen11 x16 Lanes 8GB Cache PCI SPDM Plug-in Storage Controller
Maximum storage capacity
91.2 TB
Number of HDDs installed
2
SSD interface
SATA III
RAID support
Yes
RAID levels
0, 1, 5, 6, 10, 50, 60
Hot-Plug support
Yes
Maximum storage capacity
91.2 TB
HDD interface
SATA, Serial Attached SCSI (SAS)
RAID support
Yes
RAID levels
0, 1, 5, 6, 10, 50, 60
Hot-Plug support
Yes
Optical drive type
No
Total storage capacity
16 TB
Number of HDDs installed
2
Processor
Processor cores
12
Processor manufacturer
Intel
Processor family
Intel Xeon Silver
Processor model
4510
Processor frequency
2.4 GHz
Processor cores
12
Processor cache
30 MB
Number of processors installed
1
Processor cache type
L3
Graphics
On-board graphics card
Yes
Maximum graphics card memory
16 MB
On-board graphics card
Yes
Maximum graphics card memory
16 MB
Network
LAN controller
Broadcom 57416
Ethernet LAN
Yes
Ethernet interface type
10 Gigabit Ethernet
Power
Number of main power supplies
2
Redundant power supply (RPS) support
Yes
Power supply
1000 W
Number of redundant power supplies supported
2
Number of redundant power supplies installed
1
Redundant power supply (RPS) support
Yes
Number of redundant power supplies supported
2
Number of redundant power supplies installed
1
Power supply type
2x HPE 1000W Flex Slot Titanium Hot Plug Power Supply Kit
Ports & interfaces
Ethernet LAN (RJ-45) ports
2
Expansion slots
Up to 8 PCIe Gen5, and 2 OCP 3.0, for detailed descriptions reference the QuickSpecs
Design
Chassis type
Rack (2U)
Rack mounting
Yes
Rack mounting
Yes
Performance
Trusted Platform Module (TPM)
Yes
Trusted Platform Module (TPM) version
2.0
Management platform
HPE iLO Standard with intelligent provisioning (embedded), and HPE Compute Ops Management (optional subscription available)
Software
Operating system installed
No
Operating system installed
No
Other features
Standard fans
6x Standard Fans
Storage drive type
2x HPE 8TB SATA 6G Business Critical 7.2K LFF LP 1-year Warranty 512e Multi Vendor HDD
Security features
HPE TPM 2.0 standard on motherboard. Optional locking Bezel Kit, Intrusion Detection Kit. For full security features refer to the QuickSpecs.
Number of processors supported
1
Information
| Part Number: | P71675-425 |
