Product Details
Processor
Processor cache type
L3
Processor boost frequency
4.1 GHz
Processor cores
12
Motherboard chipset
Intel C741
Number of processors installed
1
Processor manufacturer
Intel
Processor family
Intel Xeon Silver
Processor model
4510
Processor frequency
2.4 GHz
Processor boost frequency
4.1 GHz
Processor cores
12
Processor cache
30 MB
Motherboard chipset
Intel C741
Memory
Memory slots
16x DIMM
Maximum internal memory
1.5 TB
Internal memory
32 GB
Internal memory type
DDR5-SDRAM
Memory slots
16x DIMM
Memory clock speed
5600 MHz
Memory layout (slots x size)
1 x 32 GB
Maximum internal memory
1.5 TB
Storage
Maximum storage capacity
192 TB
Number of HDDs installed
2
HDD capacity
4 TB
Number of HDDs supported
4
Supported HDD sizes
3.5"
SSD interface
SATA III
RAID support
Yes
SSD interface
PCI Express 4.0
Supported RAID controllers
None
Maximum storage capacity
192 TB
Total storage capacity
8 TB
Number of HDDs installed
2
HDD capacity
4 TB
HDD interface
SATA
Number of HDDs supported
4
Supported HDD sizes
3.5"
RAID support
Yes
Optical drive type
No
Network
LAN controller
Broadcom 5720
LAN controller
Broadcom 5720
Ethernet LAN
Yes
Ethernet interface type
Gigabit Ethernet
Ports & interfaces
Expansion slots
2 to 4 x16 PCIe Gen5 and 1 x16 OCP3 slot. Refer to the QuickSpecs for more detail.
Ethernet LAN (RJ-45) ports
2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
3
VGA (D-Sub) ports quantity
1
Ethernet LAN (RJ-45) ports
2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
3
VGA (D-Sub) ports quantity
1
Performance
Management platform
Included: HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download) Optional: HPE iLO Advanced, HPE OneView Advanced (require licenses) and HPE Compute Ops Management. Refer to the iLO 6 User Guide
Trusted Platform Module (TPM)
Yes
Trusted Platform Module (TPM) version
2.0
Power
Power supply type
2x HPE 1000W Flex Slot Titanium Hot Plug Power Supply Kit
Redundant power supply (RPS) support
Yes
Number of redundant power supplies installed
1
Redundant power supply (RPS) support
Yes
Power supply
2000 W
Number of redundant power supplies installed
1
Number of main power supplies
1
Design
Chassis type
Tower (4.5U)
Other features
Standard fans
2x Standard Fans
Storage drive type
2x HPE 4TB SATA 6G Business Critical 7.2K LFF LP 1-year Warranty Multi Vendor HDD
Security features
UEFI Secure Boot and Secure Start support. Intel Software Guard Extensions (SGX) support. Immutable Silicon Root of Trust. TPM (Trusted Platform Module) 2.0 support. Front bezel key-lock feature, Intrusion cable (Optional), Padlock slot and Kensington Lock slot support. For full security features refer to the QuickSpecs.
Number of processors supported
1
Weight & dimensions
Width
195 mm
Depth
587 mm
Height
462 mm
Weight
20.4 kg
Width
195 mm
Depth
587 mm
Height
462 mm
Weight
20.4 kg
Information
| Part Number: | P77234-425 |
