Product Details
Processor
Processor boost frequency
3.4 GHz
Processor cores
16
Processor manufacturer
Intel
Processor family
Intel Xeon Silver
Processor model
4514Y
Processor frequency
2 GHz
Processor boost frequency
3.4 GHz
Processor cores
16
Processor cache
30 MB
Number of processors installed
1
Processor cache type
L3
Memory
Memory slots
16x DIMM
Maximum internal memory
4 TB
Internal memory
64 GB
Internal memory type
DDR5-SDRAM
Memory slots
16x DIMM
Memory clock speed
5600 MHz
Memory layout (slots x size)
2 x 32 GB
Maximum internal memory
4 TB
Storage
Maximum storage capacity
153.6 TB
Number of HDDs installed
2
Number of SSDs installed
2
RAID support
Yes
Number of HDDs installed
2
Supported RAID controllers
HPE MR408i-o Gen11 x8 Lanes 4GB Cache OCP SPDM Storage Controller
Maximum storage capacity
153.6 TB
Total storage capacity
960 GB
Number of SSDs installed
2
SSD capacity
480 GB
SSD interface
SATA
RAID support
Yes
Optical drive type
No
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
3
VGA (D-Sub) ports quantity
1
Ethernet LAN (RJ-45) ports
2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
3
VGA (D-Sub) ports quantity
1
Expansion slots
2-slots (x16 FH, x16 HH) as standard. Upgradeable to 3rd slot in HH (or remove Slot 2 bracket to be FH at Slot 3) in a 2nd processor configuration. And maximum 2 OCP 3.0 PCIe5 slots.
Network
LAN controller
Broadcom BCM57416
Ethernet LAN
Yes
Ethernet interface type
10 Gigabit Ethernet
Performance
Trusted Platform Module (TPM) version
2.0
Trusted Platform Module (TPM)
Yes
Trusted Platform Module (TPM) version
2.0
Management platform
Included - HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download). Optional - HPE iLO Advanced, HPE OneView Advanced and HPE Compute Ops Management Refer to the iLO 6 User Guide
Design
Chassis type
Rack (1U)
Power
Redundant power supply (RPS) support
Yes
Number of redundant power supplies installed
1
Redundant power supply (RPS) support
Yes
Power supply
2000 W
Number of redundant power supplies installed
1
Number of main power supplies
1
Power supply type
2x HPE 1000W Flex Slot Titanium Hot Plug Power Supply Kit
Weight & dimensions
Width
753.1 mm
Depth
434.6 mm
Height
42.9 mm
Width
753.1 mm
Depth
434.6 mm
Height
42.9 mm
Other features
Standard fans
5x Standard Fans
Storage drive type
2x HPE 480GB SATA 6G Read Intensive SFF BC Multi Vendor SSD
Security features
UEFI Secure Boot and Secure Start support. Intel Software Guard Extensions (SGX) support. Immutable Silicon Root of Trust. Optional Trusted Supply Chain, iLO Security modes, TPM, Chassis Intrusion detection and Bezel Locking kits. For full security features refer to the QuickSpecs.
Number of processors supported
1
Information
| Part Number: | P77237-425 |
