Product Details
Processor
Processor cache type
L3
Processor boost frequency
3.7 GHz
Processor cores
16
Processor manufacturer
AMD
Processor family
AMD EPYC
Processor model
9124
Processor frequency
3 GHz
Processor boost frequency
3.7 GHz
Processor cores
16
Processor cache
64 MB
Number of processors installed
1
Memory
Memory slots
12x DIMM
Maximum internal memory
3 TB
Internal memory
64 GB
Internal memory type
DDR5-SDRAM
Memory slots
12x DIMM
Memory clock speed
4800 MHz
Memory layout (slots x size)
2 x 32 GB
Maximum internal memory
3 TB
Storage
Maximum storage capacity
522.24 TB
Number of HDDs installed
2
Number of SSDs installed
2
RAID support
Yes
Optical drive type
No
Number of HDDs installed
2
Supported RAID controllers
HPE MR408i-o Gen11 x8 Lanes 4GB Cache OCP SPDM Storage Controller
Maximum storage capacity
522.24 TB
Total storage capacity
960 GB
Number of SSDs installed
2
SSD capacity
480 GB
SSD interface
SATA
RAID support
Yes
Optical drive type
No
Ports & interfaces
Expansion slots
8 maximum, for detailed descriptions refer to the QuickSpecs
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
3
VGA (D-Sub) ports quantity
1
Ethernet LAN (RJ-45) ports
2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
3
VGA (D-Sub) ports quantity
1
Performance
Management platform
HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download); HPE iLO Advanced, HPE iLO Advanced Premium Security Edition, HPE OneView Advanced (require licenses) and HPE Compute Ops Management (optional subscription available) Refer to the iLO 6 User Guide
Trusted Platform Module (TPM)
Yes
Trusted Platform Module (TPM) version
2.0
Trusted Platform Module (TPM)
Yes
Trusted Platform Module (TPM) version
2.0
Network
LAN controller
Broadcom BCM57416
Ethernet LAN
Yes
Ethernet interface type
10 Gigabit Ethernet
Power
Power supply type
2x HPE 1000W Flex Slot Titanium Hot Plug Power Supply Kit
Redundant power supply (RPS) support
Yes
Number of redundant power supplies installed
1
Redundant power supply (RPS) support
Yes
Power supply
2000 W
Number of redundant power supplies installed
1
Number of main power supplies
1
Design
Chassis type
Rack (2U)
Other features
Standard fans
6x Standard Fans
Storage drive type
2x HPE 480GB SATA 6G Read Intensive SFF BC Multi Vendor SSD
Security features
For full security features refer to the QuickSpecs
Number of processors supported
1
Weight & dimensions
Width
646.4 mm
Depth
434.7 mm
Height
87.5 mm
Width
646.4 mm
Depth
434.7 mm
Height
87.5 mm
Information
| Part Number: | P77245-425 |
