Product Details
Storage
Supported RAID controllers
Embedded Intel VROC SATA/NVMe
Number of HDDs installed
2
Number of SSDs installed
2
Supported SSD sizes
2.5"
Number of SSDs supported
8
RAID support
Yes
Number of HDDs installed
2
Total storage capacity
960 GB
Number of SSDs installed
2
SSD capacity
480 GB
SSD interface
SATA III
Supported SSD sizes
2.5"
Number of SSDs supported
8
RAID support
Yes
Optical drive type
No
Processor
Processor boost frequency
2.2 GHz
Processor cores
8
Processor manufacturer
Intel
Processor family
Intel Xeon Bronze
Processor model
3508U
Processor frequency
2.1 GHz
Processor boost frequency
2.2 GHz
Processor cores
8
Processor cache
22.5 MB
Number of processors installed
1
Processor cache type
L3
Performance
Trusted Platform Module (TPM)
Yes
Trusted Platform Module (TPM) version
2.0
Management platform
Included: HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download) Optional: HPE iLO Advanced, HPE OneView Advanced (require licenses) and HPE Compute Ops Management. Refer to the iLO 6 User Guide
Memory
Internal memory
32 GB
Internal memory type
DDR5-SDRAM
Memory clock speed
5600 MHz
Memory layout (slots x size)
1 x 32 GB
Ports & interfaces
Ethernet LAN (RJ-45) ports
2
Ethernet LAN (RJ-45) ports
2
Expansion slots
2 to 4 x16 PCIe Gen5 and 1 x16 OCP3 slot. Refer to the QuickSpecs for more detail.
Network
Ethernet LAN
Yes
Ethernet interface type
Gigabit Ethernet
Design
Product colour
Black
Chassis type
Tower (4.5U)
Product colour
Black
Software
Operating system installed
No
Operating system installed
No
Power
Redundant power supply (RPS) support
Yes
Number of redundant power supplies installed
1
Redundant power supply (RPS) support
Yes
Power supply
2000 W
Number of redundant power supplies installed
1
Number of main power supplies
1
Power supply type
2x HPE 1000W Flex Slot Titanium Hot Plug Power Supply Kit
Weight & dimensions
Weight
12.3 kg
Width
183 mm
Width
183 mm
Depth
630 mm
Height
600 mm
Other features
Standard fans
2x Standard Fans
Dimensions (W x D x H) (imperial)
183.1 x 629.9 x 599.9 mm (7.21 x 24.8 x 23.6")
Storage drive type
2x HPE 480GB SATA 6G Read Intensive SFF BC Multi Vendor SSD
Security features
UEFI Secure Boot and Secure Start support. Intel Software Guard Extensions (SGX) support. Immutable Silicon Root of Trust. TPM (Trusted Platform Module) 2.0 support. Front bezel key-lock feature, Intrusion cable (Optional), Padlock slot and Kensington Lock slot support. For full security features refer to the QuickSpecs.
Weight (imperial)
12.3 kg (27.1 lbs)
Number of processors supported
1
Information
| Part Number: | P81774-425 |
