Product Details
Processor
Processor boost frequency
4.1 GHz
Processor cores
8
Processor manufacturer
Intel
Processor family
Intel Xeon Silver
Processor model
4509Y
Processor frequency
2.6 GHz
Processor boost frequency
4.1 GHz
Processor cores
8
Processor cache
22.5 MB
Number of processors installed
1
Processor cache type
L3
Memory
Memory slots
32x DIMM
Maximum internal memory
8 TB
Internal memory
64 GB
Internal memory type
DDR5-SDRAM
Memory slots
32x DIMM
Memory clock speed
5600 MHz
Memory layout (slots x size)
2 x 32 GB
Maximum internal memory
8 TB
Storage
Number of HDDs installed
2
Number of SSDs installed
2
SSD size
2.5"
Number of SSDs supported
8
RAID support
Yes
Number of HDDs installed
2
Supported RAID controllers
HPE MR408i-o Gen11 x8 Lanes 4GB Cache OCP SPDM Storage Controller
Total storage capacity
960 GB
Number of SSDs installed
2
SSD capacity
480 GB
SSD interface
SATA III
SSD size
2.5"
Number of SSDs supported
8
RAID support
Yes
Optical drive type
No
Network
LAN controller
Broadcom BCM5719
Ethernet LAN
Yes
Ethernet interface type
Gigabit Ethernet
Design
Product colour
Black
Chassis type
Tower (4U)
Product colour
Black
Software
Operating system installed
No
Operating system installed
No
Power
Redundant power supply (RPS) support
Yes
Number of redundant power supplies installed
1
Redundant power supply (RPS) support
Yes
Power supply
2000 W
Number of redundant power supplies installed
1
Number of main power supplies
1
Power supply type
2x HPE 1000W Flex Slot Titanium Hot Plug Power Supply Kit
Ports & interfaces
Ethernet LAN (RJ-45) ports
4
Expansion slots
2 to 10 PCIe Gen5 (2 OCP 3.0). Refer to the QuickSpecs for more detail.
Performance
Trusted Platform Module (TPM)
Yes
Trusted Platform Module (TPM) version
2.0
Management platform
HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download); HPE iLO Advanced, HPE OneView Advanced (require licenses), and HPE Compute Ops Management.
Weight & dimensions
Width
304.8 mm
Width
304.8 mm
Depth
984.3 mm
Height
584.2 mm
Weight
43.3 kg
Other features
Standard fans
3x Standard Fans
Dimensions (W x D x H) (imperial)
304.8 x 584.2 x 984.2 mm (12 x 23 x 38.8")
Storage drive type
2x HPE 480GB SATA 6G Read Intensive SFF BC Multi Vendor SSD
Security features
UEFI Secure Boot and Secure Start support. Intel Software Guard Extensions (SGX) support. Immutable Silicon Root of Trust. TPM (Trusted Platform Module) 2.0 support. Front bezel key-lock feature, Intrusion Cable (Optional), Padlock slot and Kensington Lock slot support.
Weight (imperial)
43.3 kg (95.4 lbs)
Number of processors supported
1
Information
| Part Number: | P81775-425 |
