Product Details
Processor
Processor manufacturer
Intel
Processor family
Intel® Xeon® Gold
Processor frequency
2.1 GHz
Processor boost frequency
4 GHz
Processor cores
32
Processor cache
160 MB
Number of processors installed
1
Processor model
6530
Processor boost frequency
4 GHz
Processor cores
32
Processor model
6530
Processor cache type
L3
Memory
Internal memory
64 GB
Internal memory type
DDR5-SDRAM
Memory slots
32x DIMM
Memory clock speed
5600 MHz
Memory layout (slots x size)
2 x 32 GB
Maximum internal memory
8 TB
Memory slots
32x DIMM
Maximum internal memory
8 TB
Storage
Total storage capacity
960 GB
Number of SSDs installed
2
SSD capacity
480 GB
SSD interface
SATA III
SSD size
2.5"
Number of SSDs supported
8
RAID support
Yes
RAID levels
0, 1, 5, 10
Optical drive type
No
Number of HDDs installed
2
Number of SSDs installed
2
SSD size
2.5"
Number of SSDs supported
8
RAID support
Yes
RAID levels
0, 1, 5, 10
Supported RAID controllers
HPE MR416i-o Gen11 x16 Lanes 8GB Cache OCP SPDM Storage Controller
Number of HDDs installed
2
Network
LAN controller
Broadcom BCM57414
Ethernet interface type
10 Gigabit Ethernet, 25 Gigabit Ethernet
Ethernet LAN
Yes
Ports & interfaces
Ethernet LAN (RJ-45) ports
1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
3
VGA (D-Sub) ports quantity
1
Fiber optic connector
SFP28
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
3
VGA (D-Sub) ports quantity
1
Fiber optic connector
SFP28
Expansion slots
Up to 8 PCIe Gen5, and 2 OCP 3.0, for detailed descriptions reference the QuickSpecs
Design
Chassis type
Rack (2U)
Product colour
Black, Silver
Rack mounting
Yes
Product colour
Black, Silver
Rack mounting
Yes
Performance
Trusted Platform Module (TPM)
Yes
Trusted Platform Module (TPM) version
2.0
Management platform
HPE iLO Standard with intelligent provisioning (embedded), and HPE Compute Ops Management (optional subscription available)
Software
Operating system installed
No
Operating system installed
No
Power
Redundant power supply (RPS) support
Yes
Power supply
2000 W
Number of redundant power supplies installed
1
Number of main power supplies
1
Redundant power supply (RPS) support
Yes
Number of redundant power supplies installed
1
Power supply type
2x HPE 1000W Flex Slot Titanium Hot Plug Power Supply Kit
Weight & dimensions
Width
600 mm
Depth
998 mm
Height
273 mm
Weight
41.3 kg
Width
600 mm
Other features
Standard fans
6x High Performance Fan
Dimensions (W x D x H) (imperial)
599.9 x 998 x 273.1 mm (23.6 x 39.3 x 10.8")
Storage drive type
2x HPE 480GB SATA 6G Read Intensive SFF BC Multi Vendor SSD
Security features
HPE TPM 2.0 standard on motherboard. Optional locking Bezel Kit, Intrusion Detection Kit. For full security features refer to the QuickSpecs.
Weight (imperial)
41.3 kg (91.1 lbs)
Number of processors supported
1
Information
| Part Number: | P81787-425 |
