Introduction
Do you need a 2U single-socket server that highlights reduced power consumption and better thermals for your data and storage-centric workloads that need more PCIe lanes? The HPE ProLiant Compute DL340 Gen12 is a 2U 1P server that offers three CTO chassis that support SFF, LFF, and GPU configurations. The 3-box modular front design enhances the configuration flexibility. Due to the configuration flexibility and the energy efficiency (reduced power consumption due to better thermals within a 2U chassis), the HPE ProLiant Compute DL340 Gen12 server is ideal for customers that have a requirement for Infrastructure-as-a-Service (IaaS), Platform-as-a Service (PaaS), and Software-as-a-Service (SaaS) workloads. Powered by Intel Xeon 6 processors with up to 144 cores, increased memory capability (up to 4 TB), and high-speed PCIe Gen5, the HPE ProLiant Compute DL340 Gen12 server is a great 2U single-socket performance solution driving better datacenter efficiency.
What is new supporting point:
Powered by Intel Xeon 6 processors; Up to 144 cores per socket. Increased memory bandwidth to 6400 MT/s, up to 4 TB DDR5 memory capacity.
Processor
Processor manufacturer
Intel
Processor family
Intel® Xeon®
Processor frequency
2.2 GHz
Processor cores
12
Processor cache
48 MB
Number of processors installed
1
Processor model
6505P
Processor boost frequency
4.1 GHz
Processor cores
12
Processor cache type
L3
Memory
Internal memory
64 GB
Internal memory type
DDR5-SDRAM
Memory layout (slots x size)
1 x 64 GB
Maximum internal memory
4 TB
Memory clock speed
6400 MHz
Storage
Total storage capacity
960 GB
SSD capacity
480 GB
SSD interface
SATA III
Supported RAID controllers
HPE MR408i-o Gen11 x8 Lanes 4GB Cache OCP SPDM Storage Controller
Optical drive type
No
Supported SSD sizes
2.5"
Number of SSDs supported
8
RAID support
Yes
Network
Ethernet LAN
Yes
Ethernet interface type
Gigabit Ethernet
LAN controller
Broadcom BCM5719
Ports & interfaces
Ethernet LAN (RJ-45) ports
4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
3
Number of management ports
1 pc(s)
Expansion slots
Up to 6 PCIe Gen5, and 2 OCP 3.0, for detailed descriptions reference the QuickSpecs
Graphics
On-board graphics card
No
On-board graphics card model
Not available
Design
Chassis type
Rack (2U)
Cooling type
Active
Rack mounting
Yes
Power
Power supply
1000 W
Number of main power supplies
2
Power supply type
2x HPE 1000W M-CRPS Titanium Hot Plug Power Supply Kit
Redundant power supply (RPS) support
Yes
Performance
Management platform
HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download), HPE iLO Advanced, HPE iLO Advanced Premium Security Edition, and HPE OneView Advanced (require licenses), HPE Compute Ops Management (optional subscription available)
Weight & dimensions
Depth
969 mm
Height
270 mm
Weight
44.1 kg
Width
639.5 mm
Depth
448 mm
Height
87.5 mm
Software
Operating system installed
No
Other features
Standard fans
6x Standard Fans
Storage drive type
2x HPE 480GB SATA 6G Read Intensive SFF BC Multi Vendor SSD
Security features
For full security features refer to the QuickSpecs
Number of processors supported
1
