Product Details
Introduction
Do you need a 1U single-socket rackmount server, that maximizes rack utilization while mitigating virtualization risks in power-constrained environments? The HPE ProLiant DL320 Gen12 maximizes your rack utilization while mitigating virtualization risks in power-constrained environments. Power your workloads with a server providing greater expansion capabilities compared to previous generations. The latest Intel Xeon 6 processors with up to 144 cores, increased memory capability (up to 4 TB), and high-speed PCIe Gen5 help provide a high performance solution with better datacenter efficiency.
Processor
Processor manufacturer
Intel
Processor family
Intel® Xeon®
Processor frequency
2.2 GHz
Processor cores
12
Processor cache
48 MB
Number of processors installed
1
Processor model
6505P
Processor boost frequency
4.1 GHz
Processor cores
12
Processor cache type
L3
Memory
Internal memory
64 GB
Internal memory type
DDR5-SDRAM
Memory layout (slots x size)
1 x 64 GB
Memory slots
16x DIMM
Maximum internal memory
4 TB
Memory clock speed
6400 MHz
Storage
Total storage capacity
960 GB
SSD capacity
480 GB
SSD interface
SATA III
Supported RAID controllers
HPE MR408i-o Gen11 x8 Lanes 4GB Cache OCP SPDM Storage Controller
Optical drive type
No
Number of SSDs installed
2
Supported SSD sizes
2.5"
Number of SSDs supported
8
RAID support
Yes
Network
Ethernet LAN
Yes
Ethernet interface type
Gigabit Ethernet
LAN controller
Broadcom BCM5719
Ports & interfaces
Ethernet LAN (RJ-45) ports
4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
3
VGA (D-Sub) ports quantity
1
Number of management ports
1 pc(s)
Expansion slots
Up to 6 PCIe Gen5, and 2 OCP 3.0 with Rich IO Processor, for detailed descriptions reference the QuickSpecs
Graphics
On-board graphics card
No
On-board graphics card model
Not available
Design
Product colour
Black
Rack mounting
Yes
Chassis type
Rack (1U)
Performance
Trusted Platform Module (TPM)
Yes
Management platform
HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download), HPE iLO Advanced, HPE iLO Advanced Premium Security Edition, and HPE OneView Advanced (require licenses), HPE Compute Ops Management (optional subscription available)
Trusted Platform Module (TPM) version
2.0
Software
Operating system installed
No
Power
Power supply
1000 W
Number of main power supplies
2
Redundant power supply (RPS) support
Yes
Power supply type
2x HPE 1000W M-CRPS Titanium Hot Plug Power Supply Kit
Weight & dimensions
Depth
916 mm
Height
242 mm
Weight
26.7 kg
Width
607.5 mm
Depth
434.6 mm
Height
42.8 mm
Other features
Standard fans
7x High Performance Fans
Storage drive type
2x HPE 480GB SATA 6G Read Intensive SFF BC Multi Vendor SSD
Security features
UEFI Secure Boot and Secure Start support. Intel Software Guard Extensions (SGX) support. Intel Trust Domain Extensions (Intel TDX). Immutable Silicon Root of Trust. TPM (Trusted Platform Module) 2.0 support. Optional Trusted Supply Chain, iLO Security modes, Chassis Intrusion detection and Bezel Locking kits. For full security features refer to the QuickSpecs.
Number of processors supported
1
Information
| Part Number: | P87783-425 |
