Introduction
Are you looking for a compact, rack-optimized two-socket server that supports hybrid cloud workloads? The HPE ProLiant Compute DL360 Gen12 is a compact 1U 2P server that delivers exceptional compute performance, memory density with scalability and high-speed data transfer rate to run your most demanding applications. Powered by Intel Xeon 6 processors with up to 144 cores and up to 8 TB of memory as well as 20 EDSFF E3.S NVMe drives, the HPE ProLiant Compute DL360 Gen12 is an ideal hybrid cloud platform for enterprise applications and workloads. This server also provides extreme scalability through a hybrid front storage cage that supports not only SFF and E3.S drives, but also an OS Boot device and two front OCP NICs as optional. The HPE ProLiant Compute DL360 Gen12 is engineered for your future, with next-level security, optimized performance and efficiencies, and automated, AI-driven productivity.
What is new supporting point:
Three cooling options — air-cooling, closed-loop liquid cooling for high performance processors, and direct liquid cooling for performance/energy efficiency to support sustainability initiatives.
Ability to use up to 10 SFF or 20 EDSFF E3.S drives as well an OS Boot device and OCP NICs in the front cage.
Up to three single-wide (SW) GPUs.
HPE Integrated Lights-Out 7 (iLO 7) server management software with streamlined manageability through a redesigned GUI, Redfish API, and increased security via patented secure enclave technology.
Intel Xeon 6 processors that support up to 144 cores, up to 8 TB of DDR5 memory at speeds up to 6400 MT/s, and up to 2x average higher performance for general compute versus previous generations.
Optional front accessible boot device for quicker access and redesigned intake on front of chassis for optimal airflow and enhanced thermal efficiency.
Processor
Processor model
6505P
Processor boost frequency
4.1 GHz
Processor cores
12
Processor manufacturer
Intel
Processor family
Intel® Xeon®
Processor frequency
2.2 GHz
Processor cores
12
Processor cache
48 MB
Number of processors installed
1
Processor cache type
L3
Memory
Internal memory type
DDR5-SDRAM
Memory slots
32x DIMM
Maximum internal memory
8 TB
Internal memory
64 GB
Memory layout (slots x size)
2 x 32 GB
Memory clock speed
6400 MHz
Storage
Supported RAID controllers
Optional - HPE ProLiant Compute Smart Array Gen12 Storage Controller in Variety of protocols -including NVMe, port count, array utilities, and form factors (PCIe stand-up adapter and OCP3.0); Optional - Intel VROC Hybrid RAID for NVMe; Optional - HPE ProrLiant Compute Gen12 OS Boot Device, in rear or front accessible or internal. Please see QuickSpecs for storage controllers selection.
Optical drive type
No
Number of SSDs installed
2
Supported SSD sizes
2.5"
Number of SSDs supported
8
RAID support
Yes
Total storage capacity
960 GB
SSD capacity
480 GB
SSD interface
SATA III
Graphics
On-board graphics card
No
On-board graphics card model
Not available
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
3
VGA (D-Sub) ports quantity
1
Number of management ports
1 pc(s)
Ethernet LAN (RJ-45) ports
2
Expansion slots
Maximum 3 PCIe Gen5 slots (x16 lanes/each) & Maximum 2 OCP3.0 slots (x16 lanes/each)
Network
Ethernet LAN
Yes
Ethernet interface type
10 Gigabit Ethernet
LAN controller
Broadcom BCM57416
Design
Cooling type
Active
Rack mounting
Yes
Chassis type
Rack (1U)
Software
Operating system installed
No
Power
Power supply
800 W
Redundant power supply (RPS) support
Yes
Power supply type
2x HPE 1000W Flex Slot Titanium Hot Plug Power Supply Kit
Number of main power supplies
2
Performance
Management platform
Included - HPE iLO7 Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download). Optional - HPE iLO7 Advanced, and HPE OneView Advanced. Refer to the iLO 7 User Guide
Weight & dimensions
Width
753.1 mm
Depth
434.6 mm
Height
42.9 mm
Other features
Standard fans
5x Standard Fans
Storage drive type
2x HPE 480GB SATA 6G Read Intensive SFF BC Multi Vendor SSD
Security features
UEFI Secure Boot and Secure Start support. Intel Software Guard Extensions (SGX) support. Immutable Silicon Root of Trust. Optional Trusted Supply Chain, iLO Security modes, Chassis Intrusion detection and Bezel Locking kits. For full security features refer to the QuickSpecs.
Number of processors supported
1
