Introduction
Are you looking for a two-socket scalable server that powers data analytics and supports hybrid cloud workloads? The HPE ProLiant Compute DL380 Gen12 is a scalable 2U 2P server that delivers exceptional compute performance, memory density with scalability and high-speed data transfer rate to run your most demanding applications. Powered by Intel Xeon 6 processors with up to 144 cores and up to 8 TB of memory as well as 36 EDSFF E3.S drives, the HPE ProLiant Compute DL380 Gen12 is an ideal hybrid cloud platform for enterprise applications and workloads. The HPE ProLiant Compute DL380 Gen12 is engineered for your future, with next-level security, optimized performance and efficiencies, and automated, AI-driven productivity.
What is new supporting point:
Intel Xeon 6 processors that support up to 144 cores, up to 8 TB of DDR5 memory at speeds up to 6400 MT/s, and up to 2x average higher performance for general compute versus previous generations.
Optional front accessible boot device for quicker access.
Choice of two cooling options — air cooling or direct liquid cooling (DLC) for performance and energy efficiency to support sustainability initiatives.
Up to 36 EDSFF E3.S NVMe drives.
Up to three double-wide (DW) or eight single-wide (SW) GPUs.
HPE Integrated Lights-Out 7 (iLO 7) server management software with streamlined manageability through a redesigned GUI, Redfish API, and increased security via the patented secure enclave technology.
Processor
Processor model
6505P
Processor boost frequency
4.1 GHz
Processor cores
12
Processor manufacturer
Intel
Processor family
Intel® Xeon®
Processor frequency
2.2 GHz
Processor cache
48 MB
Number of processors installed
1
Processor cache type
L3
Memory
Memory slots
32x DIMM
Maximum internal memory
8 TB
Internal memory
64 GB
Internal memory type
DDR5-SDRAM
Memory clock speed
6400 MHz
Memory layout (slots x size)
2 x 32 GB
Storage
Number of HDDs installed
2
HDD capacity
8 TB
HDD speed
7200 RPM
HDD size
3.5"
Number of HDDs supported
12
RAID support
Yes
Total storage capacity
16 TB
HDD interface
Serial Attached SCSI (SAS)
Supported RAID controllers
HPE MR416i-o Gen11 x16 Lanes 8GB Cache OCP SPDM Storage Controller
Optical drive type
No
Graphics
On-board graphics card
No
On-board graphics card model
Not available
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
3
VGA (D-Sub) ports quantity
1
Number of management ports
1 pc(s)
Ethernet LAN (RJ-45) ports
4
Expansion slots
Up to 8 PCIe Gen5, and 2 OCP 3.0 (front or rear), for detailed descriptions reference the QuickSpecs
Design
Product colour
Black, Silver
Cooling type
Active
Chassis type
Rack (2U)
Software
Operating system installed
No
Network
LAN controller
Broadcom BCM5719
Ethernet LAN
Yes
Ethernet interface type
Gigabit Ethernet
Power
Redundant power supply (RPS) support
Yes
Power supply type
2x HPE 1000W Flex Slot Titanium Hot Plug Power Supply Kit
Power supply
1000 W
Number of main power supplies
2
Weight & dimensions
Width
727 mm
Depth
448 mm
Height
87.5 mm
Performance
Management platform
HPE iLO Standard with intelligent provisioning (embedded), HPE OneView Standard (requires download) (standard) HPE iLO Advanced, HPE OneView Advanced (optional, requires licenses), and HPE Compute Ops Management (optional subscription available). Refer to the iLO 7 User Guide
Trusted Platform Module (TPM)
Yes
Trusted Platform Module (TPM) version
2.0
Other features
Standard fans
6x Standard Fans
Storage drive type
2x HPE 8TB SAS 12G Business Critical 7.2K LFF LP 1-year Warranty 512e Multi Vendor HDD
Security features
HPE TPM 2.0 standard on motherboard. Optional locking Bezel Kit, Intrusion Detection Kit. For full security features refer to the QuickSpecs.
Number of processors supported
1
