Product Details
Processor
Processor manufacturer
Intel
Processor generation
Intel Core i9-14xxx
Processor model
i9-14900KF
Processor family
Intel® Core™ i9
Processor cores
24
Processor socket
LGA 1700
Processor threads
32
Processor operating modes
64-bit
Performance cores
8
Efficient cores
16
Processor boost frequency
6 GHz
Performance-core boost frequency
5.6 GHz
Performance-core base frequency
3.2 GHz
Efficient-core boost frequency
4.4 GHz
Efficient-core base frequency
2.4 GHz
Processor cache
36 MB
Processor cache type
Smart Cache
Box
Yes
Cooler included
No
Processor base power
125 W
Maximum turbo power
253 W
Stepping
B0
Maximum number of DMI lanes
8
Memory bandwidth supported by processor (max)
89.6 GB/s
Processor codename
Raptor Lake
Processor ARK ID
236787
Memory
Maximum internal memory supported by processor
192 GB
Memory types supported by processor
DDR4-SDRAM, DDR5-SDRAM
Memory channels
Dual-channel
Non-ECC
Yes
Memory bandwidth (max)
89.6 GB/s
Graphics
On-board graphics card
No
Discrete graphics card
No
On-board graphics card model
Not available
Discrete graphics card model
Not available
Features
Execute Disable Bit
Yes
Idle States
Yes
Thermal Monitoring Technologies
Yes
Market segment
Desktop
Use conditions
PC/Client/Tablet
Maximum number of PCI Express lanes
20
PCI Express slots version
4.0, 5.0
PCI Express configurations
1x16+1x4, 2x8+1x4
Supported instruction sets
AVX 2.0, SSE4.1, SSE4.2
Scalability
1S
CPU configuration (max)
1
Embedded options available
No
Thermal solution specification
PCG 2020A
Direct Media Interface (DMI) Revision
4.0
Export Control Classification Number (ECCN)
5A992C
Commodity Classification Automated Tracking System (CCATS)
740.17B1
Processor special features
Intel® Hyper Threading Technology (Intel® HT Technology)
Yes
Intel® Turbo Boost Technology
2.0
Intel® AES New Instructions (Intel® AES-NI)
Yes
Enhanced Intel SpeedStep Technology
Yes
Intel® Speed Shift Technology
Yes
Intel® Thermal Velocity Boost
Yes
Intel® Adaptive Boost Technology
Yes
Intel® Turbo Boost Max Technology 3.0 frequency
5.8 GHz
Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0
Yes
Intel® Thermal Velocity Boost Frequency
6 GHz
Intel® Control-flow Enforcement Technology (CET)
Yes
Intel® Thread Director
Yes
Intel VT-x with Extended Page Tables (EPT)
Yes
Intel® Secure Key
Yes
Intel® OS Guard
Yes
Intel 64
Yes
Intel Virtualization Technology (VT-x)
Yes
Intel Virtualization Technology for Directed I/O (VT-d)
Yes
Intel Turbo Boost Max Technology 3.0
Yes
Intel® Boot Guard
Yes
Intel® Deep Learning Boost (Intel® DL Boost)
Yes
Intel® Volume Management Device (VMD)
Yes
Mode-based Execute Control (MBE)
Yes
Intel® Standard Manageability (ISM)
Yes
Operational conditions
Tjunction
100 °C
Technical details
Launch date
Q4'23
Status
Launched
Logistics data
Harmonized System (HS) code
8542310001
Weight & dimensions
Processor package size
45 x 37.5 mm
Other features
L2 cache
32768 KB
Maximum internal memory
192 GB
Information
| Part Number: | BX8071514900KF |
