Product Details
Processor
Processor manufacturer
Intel
Processor generation
Intel Core Ultra (Series 2)
Processor model
250K Plus
Processor family
Intel Core Ultra 5
Processor cores
18
Processor socket
FCLGA1851
Processor threads
18
Processor operating modes
64-bit
Performance cores
6
Efficient cores
12
Processor boost frequency
5.3 GHz
Performance-core boost frequency
5.3 GHz
Performance-core base frequency
4.2 GHz
Efficient-core boost frequency
4.6 GHz
Efficient-core base frequency
3.3 GHz
Processor cache
30 MB
Processor cache type
Smart Cache
Package type
Box
Processor base power
125 W
Maximum turbo power
159 W
AI software frameworks supported by CPU
DirectML, OpenVINO, Windows ML, ONNX RT, WebNN
Maximum number of DMI lanes
8
Processor codename
Arrow Lake
Processor ARK ID
245694
Neural processor unit (NPU)
Neural processor unit (NPU)
Intel AI Boost
Sparsity support
Yes
Windows Studio effects support
Yes
AI software frameworks supported by NPU
DirectML, OpenVINO, Windows ML, ONNX RT, WebNN
Total processor performance up to
30 TOPs
NPU performance up to
13 TOPs
GPU performance up to
8 TOPs
Memory
Maximum internal memory supported by processor
256 GB
Memory types supported by processor
DDR5-SDRAM
Memory channels
Dual-channel
ECC
Yes
Graphics
On-board graphics card
Yes
Discrete graphics card
No
On-board graphics card model
Intel® Graphics
On-board graphics card base frequency
300 MHz
On-board graphics card dynamic frequency (max)
1900 MHz
Number of displays supported (on-board graphics)
4
On-board graphics card DirectX version
12.0
On-board graphics card OpenGL version
4.5
On-board graphics card maximum resolution (DisplayPort)
7680 x 4320 pixels
On-board graphics card refresh rate at maximum resolution (DisplayPort)
60 Hz
On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel)
120 Hz
On-board graphics card refresh rate at maximum resolution (HDMI)
60 Hz
On-board graphics card ID
0x7D67
Discrete graphics card model
Not available
Hardware encode/decode codecs supported
H.264, H.265 (HEVC)
Xe-cores
4
AI software frameworks supported by GPU
DirectML, OpenVINO, Windows ML, ONNX RT, WebGPU
AV1 encode/decode
Yes
Features
Execute Disable Bit
Yes
Idle States
Yes
Thermal Monitoring Technologies
Yes
Market segment
Desktop
Use conditions
Workstation, PC/Client/Tablet
Maximum number of PCI Express lanes
24
PCI Express slots version
4.0, 5.0
Supported instruction sets
AVX 2.0, SSE4.1, SSE4.2
Scalability
1S
Embedded options available
No
Thermal solution specification
PCG 2020A
Direct Media Interface (DMI) Revision
4.0
Processor special features
Intel® Hyper Threading Technology (Intel® HT Technology)
No
Intel® Turbo Boost Technology
2.0
Intel® Quick Sync Video Technology
Yes
Intel® AES New Instructions (Intel® AES-NI)
Yes
Enhanced Intel SpeedStep Technology
Yes
Intel Trusted Execution Technology
Yes
Intel® Speed Shift Technology
Yes
Intel® Thunderbolt 4
Yes
Intel® Control-flow Enforcement Technology (CET)
Yes
Intel® Thread Director
Yes
Intel VT-x with Extended Page Tables (EPT)
Yes
Intel® Secure Key
Yes
Intel® Active Management Technology (Intel® AMT)
Yes
Intel® OS Guard
Yes
Intel 64
Yes
Intel Virtualization Technology (VT-x)
Yes
Intel Virtualization Technology for Directed I/O (VT-d)
Yes
Intel® Boot Guard
Yes
Intel® Deep Learning Boost (Intel® DL Boost) on CPU
Yes
Intel® Volume Management Device (VMD)
Yes
Mode-based Execute Control (MBE)
Yes
Intel® vPro™ Platform Eligibility
Yes
Intel® Standard Manageability (ISM)
Yes
Intel® One-Click Recovery
Yes
Intel® Stable IT Platform Program (SIPP)
Yes
Intel® Remote Platform Erase (RPE)
Yes
Intel® Virtualization Technology with Redirect Protection (VT-rp)
Yes
Intel® Deep Learning Boost (Intel® DL Boost) on GPU
Yes
Intel vPro® Enterprise Platform Eligibility
Yes
Intel® Threat Detection Technology (TDT)
Yes
Intel® Total Memory Encryption - Multi Key
Yes
Operational conditions
Maximum operating temperature
105 °C
Technical details
OpenCL version
3.0
Launch date
Q1'26
Status
Launched
Weight & dimensions
Processor package size
45 x 37.5 mm
Other features
L2 cache
30720 KB
Maximum internal memory
256 GB
Graphics output
eDP1.4b, DP 2.1 UHBR20, HDMI 2.1 FRL
Information
| Part Number: | BX80768250K |
