Introduction
The JUA254 USB™ to HDMI™ Multi-Monitor Adapter works as an external video card, instantly allowing users to attach additional displays via HDMI™ connection without the hassle of a lengthy setup or having to install additional hardware. The USB™ 3.0 Display Adapter can support up to four displays running on the same computer, turning your workstation into a fully-functioning, multi-display powerhouse. This USB™ adapter works as an external video card, instantly allowing additional displays without the hassle of opening the computer casing and installing an external graphics card. You can have a second monitor with an extended display, a mirrored display, a rotational display (rotation mode not available for Mac®), or make it your primary monitor. Now enjoy true 1080p HD resolution through any Windows® or Mac® computer with a USB™ 3.0 port. These adapters are also backwards compatible with USB™ 2.0 resolutions and playback, which are ideal for office applications. The simple plug-and-play function allows you to connect your computer to a second monitor or projector within seconds to create a new visual environment on Windows® 10.
Performance
USB connector type
USB Type-A
USB connector gender
Male
USB version
3.2 Gen 1 (3.1 Gen 1)
DVI output
N
HDMI output
Y
DisplayPort output
N
Number of displays supported
1
HDMI ports quantity
1
Maximum resolution
2048 x 1152 pixels
Maximum resolution (HDMI)
2048 x 1152 pixels
Supported video modes
1080p
Output colour depth
32 bit
Mirror display mode
Y
Extended display mode
Y
Current
0.18 A
Design
Product colour
White
Housing material
Acrylonitrile butadiene styrene (ABS)
Integrated USB cable
Y
USB cable length
0.08 m
Cable type
USB 3.0
Power
Power consumption (max)
0.93 W
Output voltage
5 V
System requirements
Windows operating systems supported
Windows 10, Windows 7, Windows 8, Windows 8.1, Windows Vista, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Mac operating systems supported
Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Weight & dimensions
Width
68.3 mm
Depth
15 mm
Height
26 mm
Weight
25 g
Package width
120 mm
Package depth
97 mm
Package height
25 mm
Package weight
73.5 g
Packaging content
Quick installation guide
Y
Batteries included
N
Packaging content
1 x JUA254 USB™ to HDMI™ Multi-Monitor Adapter, 1 x Quick Installation Guide
Technical details
Master (outer) case GTIN (EAN/UPC)
24712795081071
Warranty period
2 year(s)
Logistics data
Products per master (outer) case
20 pc(s)
Master (outer) case width
225 mm
Master (outer) case length
321 mm
Master (outer) case height
180 mm
Master (outer) case gross weight
2.16 kg
Country of origin
Taiwan
Products per shipping (inner) case
5 pc(s)
Shipping (inner) case length
15 cm
Shipping (inner) case width
10.5 cm
Shipping (inner) case height
16 cm
Export Control Classification Number (ECCN)
EAR99
