Introduction
Power to work
The ThinkCentre M75s Gen 2 desktop will breeze through your toughest tasks with up to an AMD Ryzen™ 7 PRO processor and up to 128GB DDR4 memory. Multitask, create content, and crunch data easily, improving productivity and the bottom line.
Steadfast security
The Thinkcentre M75s Gen 2 small form factor desktop’s discrete Trusted Platform Module (dTPM) chip encrypts critical information and enables hardware authentication. BIOS-based Smart USB Protection prevents unauthorized access via peripheral. And AMD GuardMI technology enables power-on-to-power-off data protection with a co-processor inside the AMD Ryzen™ PRO CPU.
Convenience guaranteed
The ThinkCentre M75s Gen 2 SFF offers plenty of convenient features to help users be more comfortable and productive. A rapid-charging USB port enables fast data transmission and device charging, even when the PC is in sleep mode. Turn on the desktop with a simple key stroke. Connect multiple peripherals to a variety of ports, for seamless multitasking. Easily manage updates, diagnostics, and security from a remote location.
Energy-efficient and reliable
The M75s Gen 2 has a minimal footprint on the environment as well as on your desk. It meets global sustainability standards for Energy Star® 8.0, EPEAT® Silver, and TCO 8.0. And it’s designed and rigorously tested for durability and reliability.
Processor
Processor manufacturer
AMD
Processor family
AMD Ryzen™ 5
Processor model
5600G
Processor cores
6
Processor threads
12
Processor boost frequency
4.4 GHz
Processor frequency
3.9 GHz
Processor cache
16 MB
Processor cache type
L3
Number of processors installed
1
Processor generation
AMD Ryzen 5000 Series
Memory
Internal memory
8 GB
Maximum internal memory
128 GB
Internal memory type
DDR4-SDRAM
Memory layout (slots x size)
1 x 8 GB
Memory slots
4x DIMM
Memory clock speed
3200 MHz
Memory channels
Dual-channel
Storage
Total storage capacity
256 GB
Storage media
SSD
Optical drive type
DVD±RW
Number of storage drives installed
1
Total SSDs capacity
256 GB
Number of SSDs installed
1
SSD capacity
256 GB
SSD interface
PCI Express
NVMe
Yes
SSD form factor
M.2
Card reader integrated
Yes
Compatible memory cards
SD, SDHC, SDXC
Graphics
Discrete graphics card
No
On-board graphics card
Yes
Discrete graphics card model
Not available
On-board GPU manufacturer
AMD
On-board graphics card model
AMD Radeon Graphics
Network
Ethernet LAN
Yes
Ethernet LAN data rates
1000,100 Mbit/s
Cabling technology
10/100/1000Base-T(X)
Wi-Fi
No
Bluetooth
No
Ports & interfaces
USB 2.0 ports quantity
4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
2
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
2
HDMI ports quantity
1
HDMI version
1.4b
DisplayPorts quantity
2
DisplayPort version
1.4
Ethernet LAN (RJ-45) ports
1
Microphone in
Yes
Line-out
Yes
Combo headphone/mic port
Yes
Serial ports quantity
1
Design
Chassis type
SFF
Volume
8.2 L
Placement supported
Vertical
Cable lock slot
Yes
Cable lock slot type
Kensington
Product colour
Black
Viewing window
No
Performance
Motherboard chipset
AMD PRO 565
Audio chip
Realtek ALC623-CG
Audio system
High Definition Audio
Built-in speaker(s)
Yes
Number of speakers
1
Password protection
Yes
Password protection type
Power on, Supervisor, HDD
Trusted Platform Module (TPM)
Yes
Trusted Platform Module (TPM) version
2.0
Product type
PC
Software
Operating system installed
Windows 11 Pro
Operating system language
English
Power
Operational conditions
Operating temperature (T-T)
5 - 35 °C
Storage temperature (T-T)
-40 - 60 °C
Operating relative humidity (H-H)
20 - 80%
Storage relative humidity (H-H)
10 - 90%
Operating altitude
0 - 3048 m
Non-operating altitude
0 - 12192 m
Certificates
Certification
ErP Lot 3
MIL-STD-810H
Compliance certificates
RoHS
Sustainability
Sustainability compliance
Yes
Sustainability certificates
RoHS, TCO
Weight & dimensions
Width
92.5 mm
Depth
297.7 mm
Height
339.5 mm
Weight
5.3 kg
Packaging content
Display included
No
Mouse included
Yes
Mouse connectivity
Wired
Keyboard included
Yes
Keyboard connectivity
Wired
