Product Details
Introduction
- Multilevel security & manageability with up to Intel vProŽ Enterprise
- Removable dust shield to assist with upkeep & extend the lifecycle of the system
- Highly configurable compact PC with customizable expansion slots
- Ideal for healthcare, retail, & finance with support for up to 4 monitors
Processor
Processor generation
IntelŽ Core i7 (14th gen)
Performance cores
8
Efficient cores
12
Performance-core Max Turbo Frequency
5 GHz
Efficient-core Max Turbo Frequency
3.7 GHz
Performance-core base frequency
1.3 GHz
Efficient-core base frequency
0.9 GHz
Processor socket
LGA 1700
Processor base power
35 W
Maximum turbo power
106 W
Memory bandwidth supported by processor (max)
89.6 GB/s
Processor manufacturer
Intel
Processor family
IntelŽ Core i7
Processor model
i7-14700T
Processor cores
20
Processor threads
28
Processor boost frequency
5 GHz
Processor frequency
1.3 GHz
Processor cache
33 MB
Processor cache type
Smart Cache
Graphics
Graphics card
UHD Graphics
Discrete graphics card
No
On-board graphics card
Yes
Discrete graphics card model
Not available
On-board GPU manufacturer
Intel
On-board graphics card family
IntelŽ UHD Graphics
On-board graphics card model
Intel UHD Graphics 770
Display
Display included
No
Memory
Internal memory
16 GB
Maximum internal memory
64 GB
Internal memory type
DDR5-SDRAM
Memory layout (slots x size)
1 x 16 GB
Memory slots
2x SO-DIMM
Memory clock speed
5600 MHz
Memory channels
Dual-channel
Storage
Total storage capacity
512 GB
Storage media
SSD
Optical drive type
No
Total SSDs capacity
512 GB
Number of SSDs installed
1
SSD capacity
512 GB
SSD interface
PCI Express 4.0
NVMe
Yes
SSD form factor
M.2
M.2 SSD size
2280 (22 x 80 mm)
Self-Encrypting Drive (SED)
Yes
Card reader integrated
No
Performance
Motherboard chipset
Intel Q670
Fingerprint reader
No
Trusted Platform Module (TPM)
Yes
Product type
Mini PC
Trusted Platform Module (TPM) version
2.0
Network
Ethernet LAN
Yes
Ethernet LAN data rates
100,1000 Mbit/s
Wi-Fi
Yes
Top Wi-Fi standard
Wi-Fi 7 (802.11be)
Wi-Fi standards
Wi-Fi 7 (802.11be)
WLAN controller manufacturer
Intel
WLAN controller model
Intel Wi-Fi 7 BE200
Antenna type
2x2
Bluetooth
Yes
Bluetooth version
5.3
Ethernet interface type
Gigabit Ethernet
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
2
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
4
USB 3.2 Gen 2x2 Type-C ports quantity
1
DisplayPorts quantity
2
HDMI ports quantity
1
HDMI version
2.1
Ethernet LAN (RJ-45) ports
1
Combo headphone/mic port
Yes
Power
Power supply
135 W
Design
Chassis type
Mini PC
Volume
1 L
Cable lock slot
Yes
Cable lock slot type
Kensington
Product colour
Black
Software
Operating system language
English
Operating system installed
Windows 11 Pro
Processor special features
IntelŽ Smart Cache
Yes
Audio
Audio chip
Realtek ALC233
Audio system
High Definition Audio
Number of speakers
1
Weight & dimensions
Width
179 mm
Depth
182.9 mm
Height
36.5 mm
Weight
1.25 kg
Packaging content
Mouse included
Yes
Mouse connectivity
Wired
Keyboard included
Yes
Certificates
Certification
TCO,RoHS,ErP
Keyboard
Keyboard connectivity
Wired
Information
| Part Number: | 12TT000PUK |
