Product Details
Introduction
Small Form Big Impact
- Fast, powerful small-form factor desktop PC
- AI-accelerated features to enhance performance
- Up to 14th Gen Intel Core™ processors with Intel vPro® Enterprise
- ThinkShield security solutions to protect your data and your business
Processor
Processor generation
Intel® Core™ i7 (14th gen)
Performance cores
8
Efficient cores
12
Performance-core Max Turbo Frequency
5.3 GHz
Efficient-core Max Turbo Frequency
4.2 GHz
Performance-core base frequency
2.1 GHz
Efficient-core base frequency
1.5 GHz
Processor cache
33 MB
Processor cache type
Smart Cache
Processor base power
65 W
Maximum turbo power
219 W
Processor manufacturer
Intel
Processor family
Intel® Core™ i7
Processor model
i7-14700
Processor cores
20
Processor threads
28
Processor boost frequency
5.3 GHz
Processor frequency
2.1 GHz
Memory
Internal memory
16 GB
Maximum internal memory
64 GB
Internal memory type
DDR5-SDRAM
Memory layout (slots x size)
1 x 16 GB
Memory slots
2x DIMM
Memory clock speed
5600 MHz
Memory channels
Dual-channel
Storage
Total storage capacity
512 GB
Storage media
SSD
Optical drive type
DVD±RW
Total SSDs capacity
512 GB
Number of SSDs installed
1
SSD capacity
512 GB
SSD interface
PCI Express 4.0
NVMe
Yes
SSD form factor
M.2
Card reader integrated
Yes
M.2 SSD size
2280 (22 x 80 mm)
Self-Encrypting Drive (SED)
Yes
Graphics
Discrete graphics card
No
On-board graphics card
Yes
Discrete graphics card model
Not available
On-board GPU manufacturer
Intel
On-board graphics card family
Intel® UHD Graphics
On-board graphics card model
Intel UHD Graphics 770
Network
Ethernet LAN
Yes
Ethernet LAN data rates
100,1000 Mbit/s
Wi-Fi
No
Ethernet interface type
Gigabit Ethernet
Ports & interfaces
USB 2.0 ports quantity
4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
4
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
1
HDMI ports quantity
1
HDMI version
2.1
DisplayPorts quantity
1
Ethernet LAN (RJ-45) ports
1
Microphone in
Yes
Combo headphone/mic port
Yes
Design
Chassis type
SFF
Volume
8.2 L
Cable lock slot
Yes
Cable lock slot type
Kensington
Product colour
Black
Performance
Motherboard chipset
Intel Q670
Audio chip
Realtek ALC623-CG
Audio system
High Definition Audio
Number of speakers
1
Trusted Platform Module (TPM)
Yes
Product type
PC
Fingerprint reader
No
Trusted Platform Module (TPM) version
2.0
Software
Operating system language
English
Operating system installed
Windows 11 Pro
Power
Power supply
260 W
Processor special features
Intel® Smart Cache
Yes
Certificates
Certification
TCO,RoHS
Weight & dimensions
Width
92.5 mm
Depth
297.7 mm
Height
339.5 mm
Weight
5.3 kg
Packaging content
Mouse included
Yes
Mouse connectivity
Wired
Keyboard included
Yes
Keyboard connectivity
Wired
Information
| Part Number: | 12U8009JUK |
