Product Details
Introduction
The ThinkEdge SE30 IOBOX connects to ThinkEdge SE30 via a Type-C connection, providing extra vertical IO offerings such as Power over Ethernet (PoE), Digital Input/Output, and a Serial port (RS232/422/485) offering flexibility and adaptability during Retail, Manufacturing, and Smart Building system integration. One DC cable provides voltage input to the IOBOX and PC device simultaneously, saving customers the extra burden of an AC/DC power transfer in industrial DC power supply environments.
Ports & interfaces
Connectivity technology
Wired
Host interface
USB 3.2 Gen 1 (3.1 Gen 1) Type-C
Microphone in
N
Serial ports quantity
2
Network
Ethernet LAN
Y
Ethernet LAN (RJ-45) ports
2
Networking standards
IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u
Full duplex
Y
Performance
Card reader integrated
N
Product colour
Black
LED indicators
Power
Brand compatibility
Lenovo
Certification
CE,FCC,cTUVus,ICES,RCM,KCC,VCCI,BSMI,EAC,MOROCCO
Software
Windows operating systems supported
Windows 10 x64
Operational conditions
Operating temperature (T-T)
-20 - 60 °C
Operating relative humidity (H-H)
10 - 90%
Weight & dimensions
Width
178 mm
Depth
88 mm
Height
25.6 mm
Weight
506 g
Packaging data
Package width
227 mm
Package depth
175 mm
Package height
31 mm
Package weight
650 g
Packaging content
Warranty card
Y
User guide
Y
Other features
Overload protection
Y
Information
| Part Number: | 4XH1C95567 |
