Product Details
Introduction
The Power You Need, The Machine You Want
A powerful, AI-ready mobile workstation tailored for creatives & power users with demanding workloads.
- 16" mobile workstation with AI efficiency & Intel® Core™ Ultra (Series 2) processors
- Superior computing & fast visual rendering via up to NVIDIA RTX PRO™ 2000 Blackwell graphics
- Enterprise-grade performance, security & manageability with lntel vPro® option
Design
Market positioning
High performance
Product type
Mobile workstation
Product colour
Black
Form factor
Clamshell
Housing material
Aluminium
Display back cover material
Aluminium
Processor
Processor generation
Intel Core Ultra (Series 2)
Processor boost frequency
5.4 GHz
Performance cores
6
Efficient cores
8
Low Power Efficient-cores
2
Performance-core Max Turbo Frequency
5.4 GHz
Efficient-core Max Turbo Frequency
4.5 GHz
Low Power Efficient-core Max Turbo Frequency
2.5 GHz
Performance-core base frequency
2.9 GHz
Efficient-core base frequency
2.7 GHz
Low Power Efficient-core Base Frequency
1000 MHz
Processor cache
24 MB
Processor base power
45 W
Maximum turbo power
115 W
Processor manufacturer
Intel
Processor family
Intel Core Ultra 9
Processor model
285H
Processor cores
16
Processor threads
16
Neural processor unit (NPU)
Neural processor unit (NPU)
Intel AI Boost
Sparsity support
Yes
Windows Studio effects support
Yes
AI software frameworks supported by NPU
DirectML, OpenVINO, Windows ML, ONNX RT, WebNN
Total processor performance up to
99 TOPs
NPU performance up to
13 TOPs
GPU performance up to
77 TOPs
Display
Display diagonal
40.6 cm (16")
Display resolution
1920 x 1200 pixels
Touchscreen
No
HD type
WUXGA
Panel type
IPS
LED backlight
Yes
Native aspect ratio
16:10
Anti-glare screen
Yes
Display brightness
500 cd/m˛
RGB colour space
sRGB
Colour gamut
100%
Maximum refresh rate
60 Hz
Graphics
Discrete graphics card model
NVIDIA RTX PRO 2000 Blackwell
On-board graphics card
Yes
On-board GPU manufacturer
Intel
On-board graphics card family
Intel Arc Graphics
On-board graphics card model
Intel Arc 140T
Discrete graphics card memory
8 GB
Discrete graphics memory type
GDDR7
Discrete graphics card
Yes
Memory
Internal memory
64 GB
Internal memory type
LPDDR5x-SDRAM
Memory clock speed
7467 MHz
Maximum internal memory
64 GB
Storage
Total storage capacity
2 TB
Storage media
SSD
Total SSDs capacity
2 TB
Number of SSDs installed
1
SSD capacity
2 TB
SSD interface
PCI Express 5.0
NVMe
Yes
SSD form factor
M.2
Optical drive type
No
Card reader integrated
Yes
Compatible memory cards
SD
Audio
Number of built-in speakers
2
Speaker power
2 W
Built-in microphone
Yes
Number of microphones
2
Camera
Front camera
Yes
Front camera resolution (numeric)
5 MP
Infrared (IR) camera
Yes
Privacy camera
Yes
Privacy type
Privacy shutter
Network
Top Wi-Fi standard
Wi-Fi 7 (802.11be)
Wi-Fi standards
Wi-Fi 7 (802.11be)
Mobile network connection
No
Antenna type
2x2
WLAN controller manufacturer
Intel
Ethernet LAN
No
Bluetooth
Yes
Bluetooth version
5.4
Near Field Communication (NFC)
No
WWAN
Not installed
Ports & interfaces
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
1
HDMI ports quantity
1
HDMI version
2.1
Thunderbolt 4 ports quantity
1
Thunderbolt 5 ports quantity
2
Intel® Thunderbolt 4
Yes
Intel® Thunderbolt 5
Yes
Combo headphone/mic port
Yes
USB Sleep-and-Charge
Yes
Performance
Motherboard chipset
Intel SoC
Keyboard
Pointing device
ThinkPad UltraNav
Numeric keypad
No
Keyboard backlit
Yes
Keyboard language
English
Software
Operating system installed
Windows 11 Pro
Bundled software
Lenovo AI Now + Intel Connectivity Performance Suite
Battery
Battery capacity
90 Wh
Power
AC adapter power
140 W
USB Type-C charging port
Yes
USB Type-C required charging power (min)
140 W
USB Type-C required charging power (max)
140 W
USB Power Delivery (USB PD)
Yes
Security
Cable lock slot
Yes
Cable lock slot type
Kensington
Fingerprint reader
Yes
Smart card reader
No
Windows Hello
Yes
Trusted Platform Module (TPM)
Yes
Trusted Platform Module (TPM) version
2.0
Certificates
Certification
ENERGY STAR,TCO,EPEAT Gold,RoHS
Weight & dimensions
Width
354.3 mm
Depth
241 mm
Height (front)
9.9 mm
Height (rear)
1.58 cm
Weight
1.84 kg
Packaging content
AC adapter included
Yes
Information
| Part Number: | 21Q8003JUK |
