Product Details
Introduction
Premium Thunderbolt™ 4 Docking Experience: ThinkPad Thunderbolt 4 Workstation Dock delivers reliable and consistent industry leading video, data and power connectivity; Maximize Your Productivity: Expand your horizon with versatile 8K display support or multiple 4K displays support, Upto 230W Power Delivery to Workstation, silent firmware upgrades, VPro/AMT support and transfer data at lightning fast 40Gbps.; The ThinkPad Thunderbolt 4 Workstation Dock is future-proof and fully loaded to take your productivity, efficiency and creativity to the peak.
Ports & interfaces
Connectivity technology
Wired
Host interface
Thunderbolt 4
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
4
USB Power Delivery
Y
USB Power Delivery up to
230 W
HDMI ports quantity
1
HDMI version
2.1
DisplayPorts quantity
2
DisplayPort version
1.4
Thunderbolt 4 ports quantity
1
Microphone in
N
Combo headphone/mic port
Y
DC-in jack
Y
Network
Ethernet LAN
Y
Ethernet LAN (RJ-45) ports
1
Ethernet LAN data rates
10,100,1000 Mbit/s
Performance
Card reader integrated
N
Built-in speaker(s)
N
Data transfer rate
40 Gbit/s
HD type
8K Ultra HD
Maximum digital resolution
7680 x 4320 pixels
Number of displays supported
4
Maximum refresh rate
30 Hz
Cable lock slot
Y
Cable lock slot type
Kensington
VESA mounting
Y
Product colour
Black, Red
LED indicators
Y
Certification
cULus, FCC, ICES, NOM
Technical details
Harmonized System (HS) code
84733020
Power
Power source type
AC
Power supply
300 W
Output voltage
20 V
Output current
15 A
Power consumption (max)
230 W
Software
Windows operating systems supported
Windows 10
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Operating relative humidity (H-H)
5 - 95%
Weight & dimensions
Width
220 mm
Depth
80 mm
Height
30 mm
Weight
450 g
Packaging data
Quantity per pack
1 pc(s)
Package width
270 mm
Package depth
195 mm
Package height
85 mm
Package weight
1.9 kg
Packaging content
Warranty card
Y
Cables included
AC
AC adapter included
Y
Manual
Y
Information
| Part Number: | 40B00300UK |
