Introduction
Make productivity portable with ThinkVision M15. Its stunning form factor is meticulously designed to expand and match the screen real estate of multiple kinds of laptop, this light and slim 15.6-inch FHD resolution mobile monitor weighs just 860g while its head measures a mere 6 mm thick, making it perfect for multi-screen multitasking like spreadsheets in an airport lounge or sharing a presentation with a prospect in a restaurant.
Equipped with two identical USB Type-C ports, the monitor gives users indispensable Power Pass Through capability. That means they can power both the monitor and the laptop with a single power adapter, plugged into one port with a USB Type-C cable connected to the computer from the other port. Or they can simply power M15 from the laptop using just one USB Type-C connection. With safety ever in ThinkVision's minds, the M15 mobile monitor also comes equipped with TÜV Rheinland certified Low Blue Light technology, which protects users from eyestrain caused by certain frequencies of blue light. Simply turn it on with the press of a button.
Display
LED backlight
Yes
Pixel density
141 ppi
NTSC coverage (typical)
45%
Touchscreen
No
Display diagonal
39.6 cm (15.6")
Display brightness (typical)
250 cd/m²
Display resolution
1920 x 1080 pixels
Native aspect ratio
16:9
Response time
14 ms
HD type
Full HD
Display technology
LED
Backlight type
W-LED
Anti-glare screen
Y
Screen shape
Flat
Contrast ratio (typical)
1000:1
Contrast ratio (dynamic)
3000000:1
Maximum refresh rate
60 Hz
Viewing angle, horizontal
178°
Viewing angle, vertical
178°
Display number of colours
16.7 million colours
Panel type
IPS
Response time (fast)
6 ms
Pixel pitch
0.1793 x 0.1793 mm
Viewable size, vertical
34.4 cm
Viewable size diagonal
19.4 cm
RGB colour space
NTSC
Colour gamut
45%
Multimedia
Built-in microphone
No
Built-in camera
No
Built-in speaker(s)
N
Design
Colour name
Raven Black
Product colour
Black
Certification
ENERGY STAR
CCC
RoHS
TÜV
Network
Power
Power consumption (off)
0.3 W
Energy efficiency class (SDR)
C
Energy consumption (SDR) per 1000 hours
8 kWh
Energy efficiency scale
A to G
Power consumption (typical)
8 W
Power consumption (standby)
0.3 W
Power consumption (max)
9.5 W
Weight & dimensions
Bezel width (side)
7.3 mm
Width (with stand)
360 mm
Depth (with stand)
108.4 mm
Height (with stand)
235.5 mm
Weight (with stand)
860 g
Ports & interfaces
HDMI
No
Charging port type
USB Type-C
Built-in USB hub
Y
USB hub version
2.0 / 3.2 Gen 1 (3.1 Gen 1)
USB upstream port type
USB Type-C
Number of USB Type-C upstream ports quantity
1
USB Type-C downstream ports quantity
1
USB Type-C DisplayPort Alternate Mode
Y
Ergonomics
On Screen Display (OSD)
Yes
Panel mounting interface
100 x 100 mm
Cable lock slot
Y
Cable lock slot type
Kensington
VESA mounting
Y
Height adjustment
Y
Height adjustment
1 cm
Tiltable
Y
Tilt angle range
0 - 90°
Sustainability
European Product Registry for Energy Labelling (EPREL) code
550429
Logistics data
Harmonized System (HS) code
85285210
Packaging data
Package width
407.9 mm
Package depth
75.9 mm
Package height
279.9 mm
Package weight
1.69 kg
