LINDY Hdmi 8k60 Edid Feeder

Introduction

The Lindy HDMI® 8K60 EDID Feeder adapter is designed for systems that require an uninterrupted signal to overcome EDID related issues that commonly occur when using AV equipment such KVM's, Extenders, Splitters & Switches. With the small-scale and minimalistic design, this is a handy connectivity solution for both AV and IT installers to ensure legacy and new HDMI® equipment works seamlessly with no compromise on performance.

With support for resolutions up to 7680x4320@60Hz or 3840x2160@120Hz HDR (Via cloning), HDCP 2.3 pass-through, this emulator is perfect for use with any HDMI® device.

This adapter provides a fast and reliable way to clone EDID data directly from an HDMI® display, ensuring that your graphics card always receives accurate and consistent display information. By capturing the display’s EDID settings, it helps eliminate common compatibility issues such as incorrect resolutions, display drop-outs, or handshake problems making it ideal for professional AV installations, testing environments, and system integration work.

A key advantage of this unit is its eight independent EDID memory slots, allowing you to store and manage up to eight individual EDID profiles at once. Each slot can hold a different EDID configuration, giving you the flexibility to switch between multiple monitors, resolutions, and setups without needing to re-clone every time. Selection is made easily and instantly using the on-board DIP switch, providing full control and a clear, reliable workflow for multi-display environments or repeated installation tasks.

The cloning process takes less than 10 seconds, meaning you can capture, store, and deploy EDID data quickly – perfect for time-sensitive or high-volume installation work. For a full technical breakdown and operating instructions, please refer to the Technical Information section.

Features

Design

Ports & interfaces

Packaging content

Technical details

Operational conditions

Weight & dimensions

Packaging data
