LINDY Hdmi 8k60 Signal Generator

£168.40 (incl. VAT)

Qty:

Add to basket

Part Number:	32695
	In Stock
	Delivery: 1 - 2 days

Product Details

Introduction

This analyzer supports both FRL and TMDS signal analysis, enabling the evaluation of a wide range of HDMI® signal types up to 40G 8K60 resolution.

For real-time signal monitoring, the upper display presents comprehensive information, including video image quality, resolution, signal format, color space, bit depth, and bandwidth utilization.

It provides a LCD screen for real-time monitoring and browse the options, in addition it can be managed over serial communication though a dedicated USB-C port.

Powered over USB-C port, compact in size yet powerful in capability, the analyzer combines signal analysis, intuitive operation, and reliable performance, making it an ideal tool for HDMI® signal monitoring and diagnostics.

The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI Trade dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.

Features

Product type Signal analyzer

Product colour Black

Housing material Metal

Control type Buttons

Colour sampling 4:2:0

Built-in display Yes

Display type LCD

Resolution at capture speed 7680x4320@60fps

Colour depth 12 bit

Supported video modes 4320p

HDCP version 2.3

Dolby technologies Dolby Atmos, Dolby TrueHD, Dolby Digital Plus, DTS:X, DTS-HD Master Audio

Maximum bandwidth (HDMI) 40 Gbit/s

HDMI version 2.1

Ports & interfaces

USB port type USB Type-C

Connector type HDMI Type-A

USB Type-C ports quantity 2

Power

Power source USB Type-C

Power consumption 4.6 W

Input voltage 5 V

Input current 1.5 A

Operational conditions

Operating temperature (T-T) -5 - 55 °C

Storage temperature (T-T) -20 - 70 °C

Operating relative humidity (H-H) 0 - 80%

Certificates

Compliance certificates CE, UKCA, Federal Communications Commission (FCC), RoHS, REACH

Weight & dimensions

Width 260 mm

Depth 48 mm

Height 19 mm

Weight 113 g

Packaging content

Manual Yes

USB cable Yes

Packaging data

Package type Box

Package width 292 mm

Package depth 144 mm

Package height 32 mm

Package weight 305 g

Logistics data

Warranty period 3 year(s)
