LINDY Cable - Hdmi To DVI-d - Blackline - 2m

£9.32

Part Number: 36272
Delivery: 1 - 2 days

Product Details

Introduction

Entry level HDMI Male to DVI-D Male cable for home and small office applications_x000D_
Supports DVI resolutions up to 1920x1200@60Hz and HDTV resolutions up to 1080p_x000D_
Robust PVC housing, nickel connectors, 24K gold plated contacts_x000D_
Tripled shielded cable, corrosion resistant tinned copper 30AWG conductors_x000D_
10 year warranty_x000D_
_x000D_
From the Lines cable connectivity concept developed by Lindy, Black Line HDMI to DVI-D cables are fully featured, entry level connection solutions, perfect for connecting PCs to monitors or projectors._x000D_
_x000D_
Black Line HDMI to DVI-D cables feature triple shielded construction with 30AWG tinned copper conductors for performance and corrosion resistance. Nickel connectors and 24K gold plated contacts maintain signal integrity and reliability._x000D_
_x000D_
The tough PVC housing incorporates an integrated finger grip for easy installation. Large thumb screws allow the connector to be tightened into place without the need for a screwdriver and a flexible strain relief prolongs cable life._x000D_
_x000D_
Black Line HDMI to DVI-D cables support resolutions up to 1920x1200@60Hz including HDTV resolutions up to 1080p._x000D_
_x000D_
Black Line HDMI to DVI-D cables are available in lengths of 0.5m to 10m._x000D_
_x000D_

Features

Connector 1 form factor Straight
Connector 2 form factor Straight
Connector contacts plating Gold
Cable length 2 m
Connector 1 HDMI Type A (Standard)
Connector 2 DVI-D
Connector 1 gender Male
Connector 2 gender Male
Dual Link DVI N
Maximum resolution 1920 x 1200 pixels
Supported graphics resolutions 1920 x 1200 (WUXGA)
Data transfer rate 4.95 Gbit/s
Maximum refresh rate 60 Hz
Bend radius (min) 5.5 cm
Product colour Black
Conductor material Tinned copper
Nominal attenuation 1 €“ 825Mhz 12db
Jacket material Polyvinyl chloride (PVC)
Cable type Round cable
Connector housing material Polyvinyl chloride (PVC)
Connector material Nickel
Contact material Brass
AWG wire size 30
Cable shielding Aluminium braid
Certification RoHS, REACH, UL

Technical details

Harmonized System (HS) code 84733080

Operational conditions

Operating temperature (T-T) -20 - 80 °C
Storage temperature (T-T) -25 - 85 °C

Weight & dimensions

Cable diameter 5.5 mm
Connector 1 dimensions (WxDxH) 21.4 x 34.2 x 12.7 mm
Connector 2 dimensions (WxDxH) 36.8 x 44.5 x 12.5 mm

Packaging data

Quantity per pack 1 pc(s)
Package type Polybag
