Product Details
Features
Cable length
10 m
Connector 1
HDMI Type A (Standard)
Connector 2
HDMI Type A (Standard)
Connector 1 gender
Male
Connector 2 gender
Male
Connector 1 form factor
Straight
Connector 2 form factor
Straight
Product colour
Black
HDMI version
2.0
Supported graphics resolutions
4096 x 2160
Dolby technologies
Dolby TrueHD
Data transfer rate
10.2 Gbit/s
Supported digital audio channels (uncompressed)
32
Bandwidth
825 MHz
Maximum refresh rate
30 Hz
Connector contacts plating
Gold
Cable material
Copper
Cable type
Round cable
Cable jacket material
Polyvinyl chloride (PVC)
Shield material
Aluminium
Number of shielding layers
1
Bending radius (min)
7 cm
Colour sampling
4:4:4
Certification
RoHS, Reach, UL
Quantity per pack
1 pc(s)
Operational conditions
Operating temperature (T-T)
-10 - 80 °C
Storage temperature (T-T)
-10 - 80 °C
Weight & dimensions
Package type
Polybag
Technical details
Sustainability compliance
Yes
Compliance certificates
CE, REACH, RoHS
Information
| Part Number: | 36468 |
