Product Details
Features
Colour depth
10 bit
Nominal attenuation
?10dB/km@850nm, ?8dB/km@1300nm
Certification
California Proposition 65
Cable length
40 m
Connector 1
HDMI Type A (Standard)
Connector 2
HDMI Type A (Standard)
Connector 1 gender
Male
Connector 2 gender
Male
Connector 1 form factor
Straight
Connector 2 form factor
Straight
Product colour
Black
HDMI version
2.1
Supported graphics resolutions
3840 x 2160, 7680 x 4320, 10240 x 4320
Dolby technologies
Dolby Vision
Data transfer rate
48 Gbit/s
High Dynamic Range (HDR) supported
Y
High Dynamic Range (HDR) technology
High Dynamic Range 10+ (HDR10 Plus)
Supported digital audio channels (uncompressed)
32
Maximum refresh rate
120 Hz
AWG wire size
23
Connector contacts plating
Gold
Connector material
Gold
Cable material
Fibre optic/Copper
Cable type
Round cable
Cable jacket material
Polyvinyl chloride (PVC)
Bending radius (min)
5 cm
Colour sampling
4:4:4
Quantity per pack
1 pc(s)
Weight & dimensions
Cable diameter
4.4 mm
Package type
Carton
Packaging data
Package width
20 mm
Package depth
240 mm
Package height
194 mm
Logistics data
Products per master (outer) case
10 pc(s)
Other features
Depth
50.5 mm
Width
20.2 mm
Height
11 mm
Supported resolutions
4 10bit
Technical details
Sustainability compliance
Yes
Compliance certificates
CE, Federal Communications Commission (FCC), REACH, RoHS, UKCA
Operational conditions
Operating temperature (T-T)
-10 - 60 °C
Storage temperature (T-T)
-20 - 70 °C
Information
| Part Number: | 38514 |
