LINDY Hybrid Cable USB 3.2 G2- USB-c Male - USB-c Male - 10m - Black With DisplayPort 1.4 4 Lanes

LINDY Hybrid Cable USB 3.2 G2- USB-c Male - USB-c Male - 10m - Black With DisplayPort 1.4 4 Lanes

£231.78 (incl. VAT)

Qty:

Add to basket

Part Number:	43398
	In Stock
	Delivery: 1 - 2 days

Product Details

Introduction

The Lindy USB 3.2 Gen 1 & DP 1.4 Type C Hybrid Cable is a unique solution, which uses optical fiber as high-speed transmission medium to perfectly transmit USB 3.2 as well as DP 1.4 data over a distance of 8m. It combines data, video and USB Power Delivery into a single, high performance cable which makes it a great solution for use in modern meeting rooms and classrooms when connecting LFDs and touchpanels. A more flexible construction makes this cable simple to install, with increased resistance to RFI/EMI ensures that the cable can be installed in sensitive environments.

The cable also supports Power Delivery up to 60W (20V / 3A). Compatible with USB 3.2 Type C and Thunderbolt 3/4 equipped computers, this is a perfect extension tool for the latest laptops, Macbooks and Type C computers. With plug and play functionality, this extension cable can be installed quickly and with minimum fuss,

Features

USB version USB 3.2 Gen 1 (3.1 Gen 1)

Connector 1 USB C

Connector 2 USB C

Connector 1 gender Male

Connector 2 gender Male

Connector 1 form factor Straight

Connector 2 form factor Straight

AWG wire size 21

Cable jacket material Polyvinyl chloride (PVC)

Connector shielding Yes

Connector shield material Copper

Connector housing material Plastic

Maximum data transfer rate 5000 Mbit/s

Maximum data transfer rate 5 Gbit/s

Product colour Black

USB Power Delivery (USB PD) Yes

USB Power Delivery up to 60 W

USB Type-C DisplayPort Alternate Mode Yes

DisplayPort version 1.4

Maximum resolution 3840 x 2160 pixels

Nominal attenuation <10dB/km@850nm,<8dB/km@1300nm

Power

Output voltage 20 V

Output current (max) 3 A

Weight & dimensions

Cable length 10 m

Cable diameter 6.5 mm

Weight 610 g

Bend radius (min) 10 cm

Packaging data

Package type Box

Package width 240 mm

Package depth 240 mm

Package height 65 mm

Package weight 770 g

Packaging content

Quantity per pack 1 pc(s)

Manual Yes

Sustainability

Sustainability compliance Yes

Operational conditions

Operating temperature (T-T) -10 - 70 °C

Storage temperature (T-T) -40 - 85 °C

Certificates

Compliance certificates CE, Federal Communications Commission (FCC), REACH, RoHS, UKCA

Information

Part Number:

43398
