Product Details
Features
Connector shielding
Yes
Connector shield material
Aluminium
Jacket material
Low smoke zero halogen (LSZH)
Conductor material
Copper
Frequency
500 MHz
Bend radius (min)
7.2 cm
Harmonized System (HS) code
84733080
Product colour
White
Cable length
3 m
Cable standard
Cat6a
Cable shielding
S/FTP (S-STP)
Connector 1
RJ-45
Connector 2
RJ-45
Connector 1 gender
Male
Connector 2 gender
Male
Connector contacts plating
Gold
Cabling technology
10/100/1000Base-T(X)
AWG wire size
27
Operational conditions
Operating temperature (T-T)
-10 - 60 °C
Storage temperature (T-T)
-20 - 75 °C
Certificates
Certification
RoHS, REACH, UL
Weight & dimensions
Outer diameter
6 mm
Connector 1 dimensions (WxDxH)
11.6 x 21.5 x 8.3 mm
Connector 2 dimensions (WxDxH)
11.6 x 21.5 x 8.3 mm
Packaging data
Package type
Polybag
Quantity per pack
1 pc(s)
Information
| Part Number: | 47195 |
