LINDY Network Patch Cable - CAT6 - U/utp - Snagless - Gigabit Grey - 1.5m

LINDY Network Patch Cable - CAT6 - U/utp - Snagless - Gigabit Grey - 1.5m

£2.47 (incl. VAT)

Qty:

Add to basket

Part Number:	47703
	In Stock
	Delivery: 1 - 2 days

Product Details

Introduction

Twisted Pair Patch Cable with RJ45 connectors_x000D_
Cat.6 S/FTP PIMF _x000D_
Integrated snagless connector for latch protection_x000D_
Gold plated pins for better conductivity and elimination of signal loss_x000D_
10 year warranty_x000D_
_x000D_
Cat.6 S/FTP network cable with support for bandwidth up to 250MHz and features a snagless design with gold plated contacts for ethernet standards up to 1GBase-T._x000D_
_x000D_
Cat.6 cable for operating frequencies up to 250MHz in shielded version with braid as overall shield and foil shield for the individual wire pairs (S/FTP). Cat.6 cables are widespread throughout the professional sector. They are ideal for Gigabit Ethernet or AV extension applications. These cables are manufactured and tested according to the ISO/IEC 11801 specification. The cables are packaged individually in a polybag._x000D_
_x000D_
The gold-plated contacts ensure reliable, corrosion-free connections over extensive periods of time. A robust snagless strain relief design prevents damage to the connector latch during installation and removal._x000D_
_x000D_
Available lengths: 0.3m, 0.5m, 1m, 1.5m, 2m, 3m, 5m, 7.5m, 10m, 15m, 20m, 30m._x000D_
_x000D_
Available colours: Blue, Red, Green, Yellow, Black, White, Orange, Purple, Grey._x000D_
_x000D_

Features

Connector shielding Yes

Connector shield material Aluminium

Jacket material Polyvinyl chloride (PVC)

Conductor material Copper

Frequency 250 MHz

Bend radius (min) 7.4 cm

Harmonized System (HS) code 84733080

Product colour Grey

Cable length 1.5 m

Cable standard Cat6

Cable shielding S/FTP (S-STP)

Connector 1 RJ-45

Connector 2 RJ-45

Connector 1 gender Male

Connector 2 gender Male

Connector contacts plating Gold

Cable class E

Cabling technology 10/100/1000Base-T(X)

AWG wire size 27

Operational conditions

Operating temperature (T-T) -10 - 60 °C

Storage temperature (T-T) -20 - 75 °C

Certificates

Certification RoHS, REACH, UL, California Proposition 65

Compliance certificates REACH, RoHS, UL

Weight & dimensions

Outer diameter 6.2 mm

Connector 1 dimensions (WxDxH) 11.6 x 22.8 x 8.3 mm

Connector 2 dimensions (WxDxH) 11.6 x 22.8 x 8.3 mm

Width 11.6 mm

Depth 22.8 mm

Packaging data

Package type Polybag

Package width 194 mm

Package depth 174 mm

Package height 25 mm

Logistics data

Products per master (outer) case 80 pc(s)

Technical details

Proposition 65 Yes

Other features

Connector(s) RJ45 Male to RJ45 Male

Cable diameter 6.2 mm

Information

Part Number:

47703
