LINDY KVM Switch Hdmi 4k60 USB 3.0 Audio 4 Port

£171.41

Part Number: 39313
Delivery: 1 - 2 days

Product Details

Introduction

The Lindy 4 Port HDMI 4K60, USB 3.0 and Audio KVM Switch is a compact solution for providing access and control over four HDMI equipped PCs from a single keyboard, mouse and monitor setup.

Support for resolutions up to 4K Ultra HD 60Hz ensures the highest image quality, perfect for demanding graphical content in gaming setups, video editing or quad system control workstations. The additional support for High-Dynamic Range ensures video content can be seen with enhanced brightness, greater contrasts and a much wider colour gamut. The audio output ports on the main unit also allow users to connect headphones or speakers to add immersive 2CH audio and a microphone, pressing the Audio On/Off button on the front panel mutes these devices. These ports are not connected to the HDMI signal but to a built-in USB converter while two additional USB devices such as printer, scanner or hard drive can be connected to the USB 3.0 ports on the front panel.

The KVM switch features two switching options including push buttons on the unit and keyboard hotkeys provide simple, reliable control for the user, great for both professional and first time users.

Ports & interfaces

Number of computers controlled 4
Keyboard port type USB
Mouse port type USB
Video port type HDMI
HDMI ports quantity 5
HDMI version 2.0
USB 3.2 Gen 1 (3.1 Gen 1) Type-B ports quantity 4
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity 2
Console ports 3.5mm headphone, 3.5mm mic, HDMI, USB A
Console USB ports quantity 4
Console HDMI ports quantity 1
USB connector type USB Type-A, USB Type-B
Audio connections Yes
Headphone outputs 1
Number of microphone inputs 1
DC-in jack Yes

Performance

HD type 4K Ultra HD
Maximum resolution 4096 x 2160 pixels
Video bandwidth 60 Hz
HDCP Yes
Audio channels 2.0
HDCP version 2.2

Design

Rack mounting No
Product colour Black
Housing material Metal
LED indicators Yes
Push button Yes
Hot keys Yes

Display

Built-in display No

Power

Power source DC
Input voltage 5 V
Input current 3 A

Sustainability

Sustainability compliance Yes
Sustainability certificates Federal Communications Commission (FCC), UKCA, CE, REACH, RoHS
Compliance certificates Federal Communications Commission (FCC), UKCA, CE, REACH, RoHS

Operational conditions

Operating temperature (T-T) 0 - 50 °C
Storage temperature (T-T) -10 - 60 °C
Operating relative humidity (H-H) 5 - 80%
Storage relative humidity (H-H) 5 - 80%

Weight & dimensions

Width 231 mm
Depth 108 mm
Height 23 mm
Weight 710 g

Packaging data

Package width 292 mm
Package depth 248 mm
Package height 55 mm
Package weight 980 g
Package type Box

Packaging content

Manual Yes
AC adapter included Yes

Information

Part Number: 39313
