Introduction
The Lindy 100W 4-Port USB Desktop GaN Fast Charger is able to charge up to 4 devices simultaneously. 100W Power Delivery is supported by the 2 USB Type C ports while the 2 USB Type A ports provide fast charging with up to 18W.
Featuring 2 USB Type C female ports and 2 USB Type A female ports this charger is ideal for use with most popular smartphones and iOS devices. Supporting power delivery of 100W and PPS (Programmable Power Supply) allowing for real-time adjustment of voltage and current levels during the charging process, ensuring your device receives the precise power it needs.
The charger communicates dynamically with your device, negotiating the best charging conditions. This ensures safety, longevity, and optimal performance during each charge. Protect your device's battery with PPS fine-grained control, preventing overcharging and overheating. Enhance your battery's lifespan for long-lasting performance.
For safe charging the device includes overcharge, overcurrent, overtemperature and short circuit protection. Whether you're charging smartphones, tablets, laptops, or other gadgets, our USB Power Supply is designed to meet the diverse charging needs of your electronic devices.
Performance
Charger compatibility
Universal
Power source type
AC
USB 2.0 ports quantity
2
USB Type-C ports quantity
2
Fast charging
Yes
Fast charging technology
Adaptive Fast Charging, Power Delivery
Sockets quantity
2
Socket type
Type C (Europlug)
Charger type
Indoor
Number of simultaneously connected devices (max)
4
Programmable power supply (PPS)
Yes
Number of outputs
4 outputs
USB Power Delivery (USB PD)
Yes
Operating principle
Contact
USB Power Delivery revision
3.0
Power protection features
Over current, Over voltage, Overheating, Short circuit
Design
Product colour
White
Cable length
1.5 m
Housing material
Acrylonitrile butadiene styrene (ABS), Polycarbonate (PC)
Connector material
Copper
Gallium nitride (GaN) transistors
Yes
Power
Input voltage
100 - 240 V
Input frequency
50/60 Hz
Input current
1.5 A
Maximum power
100 W
Maximum output voltage
12 V
Minimum output voltage
5 V
Output voltage accuracy (±)
5%
AC adapter power
100 W
AC adapter output current
3 A
Port 1 output power
45 W
Port 2 output power
45 W
Port 3 output power
60 W
Port 4 output power
65 W
Output current (5V)
3 A
Output current (9V)
2 A
Output current (12V)
1.5 A
Power consumption (no load)
0.1 W
Efficiency at low load (10%)
Yes
Power plug type
Type C
Weight & dimensions
Width
90 mm
Depth
40 mm
Height
40 mm
Weight
210 g
Packaging data
Package weight
364 g
Package type
Carton
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Storage temperature (T-T)
-20 - 70 °C
Operating relative humidity (H-H)
10 - 90%
Storage relative humidity (H-H)
5 - 95%
Packaging content
Cables included
AC
Manual
Yes
Certificates
Compliance certificates
CE, REACH, RoHS, UKCA
Certification
UKCA, CE, RoHS, REACH, ErP
Logistics data
Warranty period
2 year(s)
