Introduction
FIND THE BEST FIT FOR YOUR LARGE ROOM
In large rooms with one or two displays, deploy Rally with tremendous flexibility and ease.
SIMPLE TO USE
Start your meeting with just one touch, seamlessly connecting Rally to your preconfigured room solution.
LOOKS BRILLIANT
Upgrade your large room meeting experience with cinema-quality video, outstanding color, and exceptional optical accuracy.
STAYS FOCUSED
Using AI, human figure detection, and automated PTZ, Rally adapts to meeting dynamics and keeps the camera on the action.
SOUNDS AWESOME
Rally's ultra-low distortion speakers deliver crystal clear, room-filling sound and make sure every voice is clearly heard.
PICKS UP VOICES AT EVERY SEAT
Rally's exquisitely sensitive mic pods ensure that everyone in the meeting is clearly heard.
Auto-level loud and soft voices - while suppressing unwanted noise - with AI-based RightSoundT technology that improves over time.
EXPAND THE CONVERSATION
Add up to 7 mic pods to accommodate larger groups and provide convenient access to mute controls.
SIMPLE TO MANAGE
Monitor and manage your meeting room devices from one single platform with Logitech Sync. Plus, get business insights into how your rooms are being used.
DEVICE MANAGEMENT TECHNOLOGY PARTNERS
Our integration with partner solutions and dashboards means you can easily manage your devices in other platforms.
REDUCE YOUR CARBON FOOTPRINT
Support remote workers and reduce business travel by replacing in-person meetings with video meetings that are as natural as face-to-face.
WELCOME TO THE FAMILY
Explore Logitech's beautifully simple, next generation of small, medium, and large room solutions that can be deployed in PC or appliance mode.
Performance
Pan speed
70 °/sec
Tripod mounting supported
Yes
Number of persons
16 person(s)
Product colour
Black
Product type
Group video conferencing system
Pan range
-90 - 90°
Tilt speed
70 °/sec
Tilt angle range
-90 - 50°
PTZ control
Y
Audio
Frequency range
300 - 10000 Hz
Output level
95/100 dB
Noise reduction
Yes
Sample rates
0 - 48 kHz
Echo cancellation
Y
Microphone pick-up range
4.5 m
Ports & interfaces
USB connector type
USB Type-A, USB Type-B, USB Type-C
HDMI ports quantity
4
USB 2.0 ports quantity
3
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
3
USB 3.2 Gen 1 (3.1 Gen 1) Type-B ports quantity
2
Ethernet LAN (RJ-45) ports
3
DC-in jack
Y
Line-in
Y
Camera
Zoom capability
Yes
Field of view (FOV) angle
90°
Focus adjustment
Auto
Digital zoom
15x
Number of camera presets
3
Microphone
Microphone colour
Black
Microphone direction type
Omnidirectional
Sound pressure level (max)
95 dB
Number of microphone arrays
2
Microphone sensitivity
-27 dB
Microphone frequency
90 - 16000 Hz
Microphone mute
Y
Number of microphones
4
Features
Telepresence
No
Cable lock slot
Y
Cable lock slot type
Kensington
Computer system
Windows operating systems supported
Yes
Mac operating systems supported
MacOS
Other operating systems supported
ChromeOS
Weight & dimensions
Microphone dimensions (WxHxD)
102 x 102 x 21 mm
Speaker dimensions (WxDxH)
449 x 80 x 103 mm
Camera dimensions (WxDxH)
152 x 152 x 182.5 mm
Package width
210 mm
Package depth
400 mm
Package height
690 mm
Package weight
11.2 kg
Packaging content
External interface module included
Yes
Power cable length
1.5 m
Networking cable length
5 m
HDMI cable length
2 m
AC adapter included
Yes
Camera included
Yes
Microphone included
Yes
Quick start guide
Yes
Packaging content
Rally camera
Rally display hub
Rally table hub
Rally speaker (x1)
Rally mic pod (x1)
Remote control
USB Type C to USB Type C
USB Type A to USB Type B
CAT6A Ethernet cable
HDMI Type A (x2)
A/C cables (x2)
Power supplies (x2)
Documentation
2-year manufacturer’s guarantee
Batteries included
Yes
Cables included
AUX, HDMI, LAN (RJ-45), USB
Speaker included
Y
Remote control included
Y
System requirements
Minimum system requirements
– Windows 7, Windows 8.1 or Windows 10
– macOS 10.10 or higher
– Chrome OS
Resolutions higher than 1080p
– Windows 8.1 or higher or macOS 10.10 or higher
– USB 3.0 port and Type C cable
– Compatible software
Technical details
Harmonized System (HS) code
85176990
Video
HD type
4K Ultra HD
Supported video modes
720p,1080p,1440p
Maximum frame rate
60 fps
Interface module
Interface module HDMI input ports quantity
2
Interface module HDMI output ports quantity
2
Network
Logistics data
Master (outer) case gross weight
12.3 kg
Master (outer) case length
417 mm
Master (outer) case width
227 mm
Master (outer) case height
722 mm
Battery
Battery capacity (Watt-hours)
0.675 Wh
Power
Power source type
AC
Battery technology
Lithium-Ion (Li-Ion)
Battery capacity
220 mAh
Number of batteries supported
2
