Product Details
Introduction
The purchase of a one year Logitech extended warranty along with the purchase of Rally Bar Mini adds one additional year to the original Logitech manufacturer's two year limited hardware warranty and is intended to ensure that your Logitech hardware is free from defects in material and workmanship. This extended warranty helps to protect your investment, maximize its value, and ensure optimal performance of your Logitech conference room hardware for a total of three years. This is right in line with the typical depreciation and replacement cycle of most conference room equipment.
Audio
Line-out impedance
4 O
Audio beamforming
Yes
Noise reduction
Yes
Echo cancellation
Yes
RMS rated power
8 W
Sample rates
0 - 48 kHz
Built-in speaker(s)
Y
Output level
90/99 dB
Output voltage Total Harmonic Distortion (THD)
2%
Microphone pick-up range
4.5 m
Ports & interfaces
HDMI ports quantity
3
HDMI output ports quantity
2
HDMI input ports quantity
1
USB connector type
USB Type-A, USB Type-C
Ethernet LAN (RJ-45) ports
1
DC-in jack
Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
3
Microphone in
Y
Network
Supported network protocols
IPv4, IPv6
Ethernet LAN
Y
Ethernet LAN data rates
10,100,1000 Mbit/s
Wi-Fi
Y
Wi-Fi standards
802.11a,802.11b,802.11g,Wi-Fi 4 (802.11n),Wi-Fi 5 (802.11ac)
Security algorithms
128-bit AES
Camera
Zoom capability
Yes
Vertical field of view
80.7°
Diagonal field of view
120°
Digital zoom
4x
Field of view (FOV) angle
120°
Horizontal field of view
113°
Remote control interface
Bluetooth
Microphone
Microphone direction type
Omnidirectional
Microphone sensitivity
-36 dB
Microphone frequency
90 - 16000 Hz
Sound pressure level (max)
90 dB
Number of microphones
6
Computer system
Windows operating systems supported
Yes
Mac operating systems supported
MacOS
Power
Power plug type
Type C
Power source type
AC
AC input voltage
100 - 240 V
Current
4.754 A
DC input voltage
19 V
Battery technology
Lithium-Ion (Li-Ion)
Battery capacity
220 mAh
Number of batteries supported
2
Packaging content
AC adapter included
Yes
Quick start guide
Yes
Packaging content
Rally Bar Mini Power supply AC power cord HDMI cable USB cable Remote control Lens caps for main lens and AI Viewfinder User documentation
Batteries included
Yes
Cables included
AC, DC, HDMI, USB Type-A to USB Type-C
Power cable length
2.5 m
HDMI cable length
2 m
Remote control included
Y
System requirements
Minimum system requirements
Internet Connection: Wired or wireless
USB Mode: Windows 11, Windows 10, the two most recent versions of macOS
Appliance Mode: Room solution software licence (not included)
Technical details
Harmonized System (HS) code
85176990
Performance
Product colour
Graphite
Product type
Group video conferencing system
Pan range
-25 - 25°
Tilt angle range
-15 - 15°
PTZ control
Y
Video
HD type
4K Ultra HD
Supported video modes
720p,900p,1440p,2160p
Maximum frame rate
30 fps
Interface module
Interface module HDMI ports quantity
3
Interface module HDMI input ports quantity
1
Interface module HDMI output ports quantity
2
Interface module Ethernet LAN (RJ-45) ports
1
Features
Telepresence
N
Logistics data
Master (outer) case gross weight
6.29 kg
Master (outer) case length
804 mm
Master (outer) case width
200 mm
Master (outer) case height
212 mm
Battery
Battery capacity (Watt-hours)
0.675 Wh
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Operating relative humidity (H-H)
10 - 95%
Storage temperature (T-T)
-40 - 70 °C
Heat dissipation
64 BTU/h
Weight & dimensions
Width
719 mm
Depth
101 mm
Height
91.4 mm
Weight
4.03 kg
Package width
191 mm
Package depth
789 mm
Package height
199 mm
Package weight
5.8 kg
Information
| Part Number: | 960-001339 |
