Introduction
The Neomounts by Newstar wall mount, model LED-VW1000BLACK is a fixed wall mount for flat screens up to 75" (191 cm). This mount is a great choice when you want the ultimate viewing flexibility with your flat screen. Depth of this mount is 5,6 to 21,5 centimetres. This wall mount is specially made to be used in video walls. The screen easily can be pulled out.
Neomounts by Newstar LED-VW1000BLACK is suitable for flat screens up to 75" (191 cm). The weight capacity of this product is 50 kg each screen. The wall mount is suitable for screens that meet VESA hole pattern 200x200 to 600x400mm.
Create a clean design videowall presentation with the Neomounts by Newstar LED-VW1000BLACK videowall mount solution!
Packaging data
Package weight
9.2 kg
Package width
112 mm
Package depth
115 mm
Package height
980 mm
Mounting
Maximum weight capacity (per display)
50 kg
Panel mounting interface
600 x 400 mm
Minimum screen size
81.3 cm (32")
Maximum weight capacity
50 kg
Maximum screen size
190.5 cm (75")
Mounting type
Wall
Minimum VESA mount
200 x 200 mm
Maximum VESA mount
600 x 400 mm
Number of displays supported
1
Weight & dimensions
Weight
7.8 kg
Design
Type
Fixed floor stand
Housing material
Steel
Accepts padlock
Yes
Product colour
Black
Logistics data
Quantity per master (outer) case
3 pc(s)
Master (outer) case net weight
27.6 kg
Harmonized System (HS) code
HS83025000
Products per pallet (EU)
48 pc(s)
Master (outer) case width
1010 mm
Master (outer) case length
360 mm
Master (outer) case height
140 mm
Master (outer) case gross weight
27.6 kg
Products per master (outer) case
3 pc(s)
Ergonomics
Distance to the wall (min)
5.6 cm
Distance to the wall (max)
21.5 cm
Technical details
Package net weight
9.19 kg
Other features
Country of origin
China
Information
| Part Number: | LED-VW1000BLACK |
