Introduction
The Neomounts by Newstar wall mount, model LFD-W1000 is a fixed wall mount for flat screens up to 100". This mount is a great choice when you want the ultimate viewing flexibility with your flat screen. Depth of this mount is 3.2 centimetres.
Neomounts by Newstar LFD-W1000 is suitable for screens up to 100" (254 cm). The weight capacity of this product is 125 kg. The wall mount is suitable for screens that meet VESA hole pattern 200x200 to 900x600mm.
Create a clean design ambiance for your flat screen TV in the living room, bedroom or home cinema.
All installation material is included with the product.
Packaging data
Package weight
6.3 kg
Package width
415 mm
Package depth
40 mm
Package height
1115 mm
Mounting
Maximum weight capacity (per display)
125 kg
Panel mounting interface
800 x 600 mm
Minimum screen size
152.4 cm (60")
Maximum weight capacity
125 kg
Maximum screen size
2.54 m (100")
Minimum VESA mount
200 x 200 mm
Maximum VESA mount
900 x 600 mm
Number of displays supported
1
Mounting type
Wall
Weight & dimensions
Weight
4.55 kg
Ergonomics
Type
Fixed
Distance to the wall (max)
3.2 cm
Design
Housing material
Steel
Product colour
Black
Technical details
Package net weight
6.25 kg
Logistics data
Master (outer) case width
1130 mm
Master (outer) case length
180 mm
Master (outer) case height
430 mm
Master (outer) case gross weight
25 kg
Master (outer) case net weight
25 kg
Products per master (outer) case
4 pc(s)
Harmonized System (HS) code
HS83025000
Products per pallet (EU)
44 pc(s)
Other features
Country of origin
China
Information
| Part Number: | LFD-W1000 |
