Introduction
EASY POE CONTROLS
Manage PoE prioritization, PoE power limit per port, PoE scheduling and more for advanced control over all PoE-powered devices
GIGABIT ETHERNET
5 ports provide gigabit Ethernet connectivity to your devices
VLANS
Port-based and 802.1Q-based network separation into smaller groups for more secure and efficient use of network resources
FANLESS DESIGN
Silent operation makes this switch perfect for noise-sensitive environments
VERSATILE MOUNTING OPTIONS
Place your switch on your desktop or mount it to your wall with the hardware provided in the box. Silent operation makes this switch perfect for noise-sensitive environments
ENERGY EFFICIENT
Energy Efficient Ethernet (IEEE 802.3az) standard, which reduces energy consumption when there is light traffic on an active port or when there is no link or no activity detected
Management features
Switch type
Unmanaged
Quality of Service (QoS) support
Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity
5
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
Network
Networking standards
IEEE 802.1p, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az
10G support
No
Copper ethernet cabling technology
1000BASE-T, 100BASE-T, 10BASE-T
Port mirroring
Yes
Full duplex
Yes
Flow control support
Yes
Link aggregation
Yes
Broadcast storm control
Yes
Rate limiting
Yes
VLAN support
Yes
Data transmission
MAC address table
2000 entries
Store-and-forward
Yes
Jumbo frames support
Yes
Jumbo frames
9216
Packet buffer memory
1.5 MB
Security
DHCP features
DHCP client
IGMP snooping
Yes
Multicast features
Multicast MAC address table
4000 entries
Design
Rack mounting
No
Stackable
No
Form factor
Desktop/Wall-Mounting
Product colour
Grey
Housing material
Metal
LED indicators
Activity, Link, PoE, Power, Speed, Status
Performance
Fanless
Yes
Mean time between failures (MTBF)
842428 h
Power
Power source
AC/DC
Power supply included
No
DC input voltage
54 V
Input current
1.66 A
Power consumption (max)
141.4 W
Power over Ethernet (PoE)
Power over Ethernet (PoE)
Yes
Power over Ethernet (PoE) ports quantity
4
Power over Ethernet (PoE) power per port
30 W
Total Power over Ethernet (PoE) budget
123 W
Other features
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Storage temperature (T-T)
-20 - 70 °C
Operating relative humidity (H-H)
0 - 90%
Storage relative humidity (H-H)
0 - 95%
Operating altitude
0 - 3000 m
Heat dissipation
3.24 BTU/h
Weight & dimensions
Width
158 mm
Depth
101 mm
Height
27 mm
Weight
400 g
Packaging content
Quick start guide
Yes
Manual
Yes
Certificates
Compliance certificates
CB, CE, Federal Communications Commission (FCC)
Certification
CB, CE LVD, CSA
