Product Details
Management features
Switch type
Unmanaged
Quality of Service (QoS) support
Y
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity
8
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
Network
Networking standards
IEEE 802.1p,IEEE 802.3af,IEEE 802.3at,IEEE 802.3az,IEEE 802.3x
Full duplex
Y
Data transmission
Switching capacity
16 Gbit/s
MAC address table
4000 entries
Jumbo frames support
Y
Jumbo frames
9000
Design
Rack mounting
Y
Product colour
Black
LED indicators
Y
Wall mountable
Y
Certification
CE, FCC, ICES-003, VCCI, RCM, BSMI, KC, CB, CE LVD, BSMI, EAC, RCM, KC, EN 60950-1
Performance
Buffer size
192 KB
Plug and Play
Y
Mean time between failures (MTBF)
2752476 h
Power
DC input voltage
54 V
Output voltage
2.4 V
Power consumption (typical)
123 W
Power over Ethernet (PoE)
Power over Ethernet (PoE)
Y
Power over Ethernet plus (PoE+) ports quantity
8
Power over Ethernet (PoE) power per port
30 W
Total Power over Ethernet (PoE) budget
123 W
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Storage temperature (T-T)
-20 - 70 °C
Operating relative humidity (H-H)
0 - 90%
Storage relative humidity (H-H)
0 - 95%
Operating altitude
0 - 3000 m
Weight & dimensions
Width
236 mm
Depth
102 mm
Height
27 mm
Information
| Part Number: | GS108PP-100EUS |
