Product Details
Introduction
RELIABLE PERFORMANCE
Superior network performance at non-blocking rate delivers true gigabit speed with no compromise
ENERGY EFFICIENT
Energy Efficient Ethernet (IEEE 802.3az) standard, which reduces energy consumption when there is light traffic on an active port or when there is no link or no activity detected
PLUG-AND-PLAY
No software to install. No configuration needed. Zero maintenance required
SILENT OPERATION
The fanless design means zero added noise wherever its located, making it ideal for noise-sensitive environments
VERSATILE MOUNTING OPTIONS
Install your switch on your desktop or mount it to your wall with the hardware provided in the box
METAL CASE
Durable and rugged case for long-lasting performance
Management features
Switch type
Unmanaged
Switch layer
L2
Quality of Service (QoS) support
Yes
Web-based management
Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity
16
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
Power connector
DC-in jack
Network
Networking standards
IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G support
No
Copper ethernet cabling technology
1000BASE-T, 100BASE-TX, 10BASE-T
Port mirroring
Yes
Rate limiting
Yes
VLAN support
Yes
Virtual LAN features
Port-based VLAN
Data transmission
Jumbo frames support
Yes
Security
IGMP snooping
Yes
Design
Rack mounting
No
Product colour
Black
Safety
CE/LVD, EN 60950, CB, CCC
Electromagnetic compatibility
CE mark (commercial), EN 55022 (CISPR 22) Class A, FCC Part 15 Class A, VCCI Class A, C-Tick
Performance
Compatible operating systems
Microsoft Windows 7/Vista/XP
Power
Input current
1.5 A
Input voltage
12 V
Power over Ethernet (PoE)
Power over Ethernet (PoE)
No
Operational conditions
Operating temperature (T-T)
0 - 50 °C
Operating relative humidity (H-H)
0 - 90%
Weight & dimensions
Width
286 mm
Depth
102 mm
Height
27 mm
Weight
890 g
Packaging content
Quick start guide
Yes
User guide
Yes
Manual
Yes
Logistics data
Harmonized System (HS) code
85176990
Information
| Part Number: | GS116-300EUS |
