Introduction
EASY POE CONTROLS
Manage PoE prioritization, PoE power limit per port, PoE scheduling and more for advanced control over all PoE-powered devices
GIGABIT ETHERNET AND FIBER
15 ports provide Gigabit Ethernet connectivity to your devices and 1 SFP fiber port for long distance connections
VLANS
Port-based and 802.1Q-based network separation into smaller groups for more secure and efficient use of network resources
FANLESS DESIGN
Silent operation makes this switch perfect for noise-sensitive environments
VERSATILE MOUNTING OPTIONS
Place your switch on your desktop or mount it to your wall with the hardware provided in the box. Silent operation makes this switch perfect for noise-sensitive environments
ENERGY EFFICIENT
Energy Efficient Ethernet (IEEE 802.3az) standard, which reduces energy consumption when there is light traffic on an active port or when there is no link or no activity detected
Management features
Switch type
Managed
Switch layer
L2/L3
Quality of Service (QoS) support
Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity
16
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
Installed SFP modules quantity
1
SFP module slots quantity
1
Network
Networking standards
IEEE 802.1p, IEEE 802.3az
Rate limiting
Yes
Ethernet LAN data rates
1000 Mbit/s
VLAN support
Yes
Virtual LAN features
Port-based VLAN
Number of VLANs
64
Data transmission
Switching capacity
1 Gbit/s
MAC address table
8000 entries
Jumbo frames support
Yes
Jumbo frames
10000
Packet buffer memory
4.1 MB
Security
IGMP snooping
Yes
Queue scheduling algorithms
Strict Priority Queue (SPQ), Weighted Round Robin (WRR)
Multicast features
Multicast support
Yes
Number of multicast groups filtered
128
Design
Product colour
Grey
Housing material
Metal
Performance
Mean time between failures (MTBF)
5704358 h
Power
Power source
AC/DC
Power consumption (max)
250.6 W
Power over Ethernet (PoE)
Power over Ethernet (PoE)
Yes
Power over Ethernet plus (PoE+) ports quantity
15
Power over Ethernet (PoE) power per port
30 W
Total Power over Ethernet (PoE) budget
231 W
Other features
Bandwidth
32 Gbit/s
Warranty period
5 year(s)
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Operating relative humidity (H-H)
0 - 90%
Storage relative humidity (H-H)
0 - 95%
Operating altitude
0 - 3000 m
Weight & dimensions
Width
286 mm
Depth
101 mm
Height
27 mm
Weight
830 g
Packaging content
Quick start guide
Yes
Manual
Yes
Certificates
Compliance certificates
BSMI, CE, Federal Communications Commission (FCC), KC, VCCI
