Product Details
General
Model
GS305PPv3
Type
Fixed Port
Technical Features
Port Count
5
Management
Unmanaged
Routing/Switching
Layer 2
Uplink Speed/Media
10/100/1000 Copper
High Availability
None
Features
PoE+
Fan-less
Fan-less
Ports/Interfaces
RJ-45
Form Factor
Mounting
Desktop
Management features
Switch type
Unmanaged
Quality of Service (QoS) support
Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity
4
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity
5
Power connector
DC-in jack
Network
Networking standards
IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
10G support
No
Copper ethernet cabling technology
10BASE-T, 100BASE-TX, 1000BASE-T
Full duplex
Yes
Auto MDI/MDI-X
Yes
Auto-sensing
Yes
Auto-negotiation
Yes
Cable length detection
Yes
Data transmission
Switching capacity
10 Gbit/s
Forwarding rate
1.448 Mpps
MAC address table
2000 entries
Latency (1 Gbps)
2.4 µs
Jumbo frames support
Yes
Jumbo frames
9216
Packet buffer memory
128 MB
Design
Rack mounting
No
Product colour
Black
Housing material
Metal
Reset button
Yes
LED indicators
Activity, Link, PoE, Power
Wall mountable
Yes
Performance
Mean time between failures (MTBF)
6710127 h
Other features
Warranty period
3 year(s)
Power
Power source
DC
DC input voltage
54 V
Input current
1.66 A
Power consumption (typical)
2.89 W
Power consumption (max)
88.89 W
Power over Ethernet (PoE)
Power over Ethernet (PoE)
Yes
Power over Ethernet plus (PoE+) ports quantity
4
Power over Ethernet (PoE) power per port
30 W
Total Power over Ethernet (PoE) budget
83 W
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Storage temperature (T-T)
-20 - 70 °C
Operating relative humidity (H-H)
10 - 90%
Storage relative humidity (H-H)
5 - 95%
Heat dissipation
304 BTU/h
Weight & dimensions
Width
158 mm
Depth
101 mm
Height
29 mm
Weight
410 g
Packaging content
Manual
Yes
Packaging data
Package width
269 mm
Package depth
73 mm
Package height
215 mm
Package weight
1.3 kg
Technical details
Shipping (inner) case height
37.5 cm
Shipping (inner) case width
45.1 cm
Shipping (inner) case length
25.5 cm
Shipping (inner) case net weight
15.1 kg
Products per shipping (inner) case
10 pc(s)
Certificates
Certification
CE Mark, FCC Part 15 Class B, IC Class B, RCM, CCC, VCCI, CB, CE
VD, CCC
Logistics data
Master (outer) case width
237 mm
Master (outer) case length
469 mm
Master (outer) case height
306 mm
Master (outer) case gross weight
8.52 kg
Products per master (outer) case
6 pc(s)
Information
| Part Number: | GS305PP-300EUS |
