Product Details
Introduction
PLUG-AND-PLAY
Simple set up with no software to install or configuration needed
NON-BLOCKING SWITCHING
Non-blocking switching architecture for maximum throughput at wire speed
FANLESS DESIGN
Silent operation makes this switch perfect for noise-sensitive environments
VERSITILE MOUNTING OPTIONS
Install your switch on your desktop or mount it to your wall with the hardware provided in the box
ENERGY EFFICIENT
Energy Efficient Ethernet (IEEE 802.3az) standard, which reduces energy consumption when there is light traffic on an active port or when there is no link or no activity detected
FLEX PoE
Easily increase you power budget on this switch to meet your changing power needs.
Management features
Switch type
Unmanaged
Quality of Service (QoS) support
Yes
Traffic classification
Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity
8
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
Network
Networking standards
IEEE 802.3az, IEEE 802.1p, IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3af, IEEE 802.3at
10G support
No
Copper ethernet cabling technology
10BASE-T, 100BASE-TX, 1000BASE-T
Cable types supported
Cat5e
Full duplex
Yes
Half duplex
Yes
Flow control support
Yes
Auto MDI/MDI-X
Yes
Ethernet LAN data rates
10,100,1000 Mbit/s
Auto-sensing
Yes
Auto-negotiation
Yes
MAC address auto-learning supported
Yes
MAC address auto-aging supported
Yes
Data transmission
Switching capacity
16 Gbit/s
Throughput
16 Gbit/s
Forwarding rate
1.488 Mpps
MAC address table
4000 entries
Latency (1 Gbps)
2.6 µs
Number of queues
8
Jumbo frames support
Yes
Jumbo frames
9216
Packet forwarding rate (1 Gbps)
1488000 pps
Packet buffer memory
0.192 MB
Security
Queue scheduling algorithms
Weighted Round Robin (WRR)
MAC address entries
Dynamic MAC address entries
Design
Rack mounting
Yes
Stackable
No
Form factor
Desktop
Product colour
Black
Housing material
Metal
LED indicators
Yes
Wall mountable
Yes
Performance
Fanless
Yes
Mean time between failures (MTBF)
2752476 h
Power
Power source
DC
Power supply included
Yes
Number of power supply units
1
DC input voltage
54 V
Input current
1.25 A
Input voltage
54 V
Power consumption (max)
67.5 W
Power over Ethernet (PoE)
Power over Ethernet (PoE)
Yes
Power over Ethernet (PoE) type supported
PoE+
Power over Ethernet (PoE) ports quantity
8
Power over Ethernet plus (PoE+) ports quantity
8
Power over Ethernet (PoE) power per port
30 W
Total Power over Ethernet (PoE) budget
60 W
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Storage temperature (T-T)
-20 - 70 °C
Operating relative humidity (H-H)
0 - 90%
Storage relative humidity (H-H)
0 - 95%
Operating altitude
0 - 3000 m
Heat dissipation
230.85 BTU/h
Weight & dimensions
Width
236 mm
Depth
102 mm
Height
27 mm
Weight
600 g
Certificates
Compliance certificates
CE, Federal Communications Commission (FCC), Industry Canada (IC), RCM, VCCI, KC, CB, Low Voltage Directive (LVD)
Information
| Part Number: | GS308LP-100EUS |
