Product Details
Management features
Switch type
Managed
Switch layer
L2/L3
Quality of Service (QoS) support
Yes
Web-based management
Yes
System event log
Yes
MIB support
Y
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity
8
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
SFP module slots quantity
2
Power connector
DC-in jack
Network
Networking standards
IEEE 802.1D, IEEE 802.1ab, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3at, IEEE 802.3az, IEEE 802.3x
Port mirroring
Yes
Flow control support
Yes
Link aggregation
Yes
Broadcast storm control
Yes
Rate limiting
Yes
Spanning tree protocol
Yes
Ethernet LAN data rates
10,100,1000 Mbit/s
Auto-negotiation
Yes
VLAN support
Yes
Virtual LAN features
Voice VLAN
Number of VLANs
64
Data transmission
Switching capacity
20 Gbit/s
MAC address table
8000 entries
Jumbo frames support
Yes
Jumbo frames
10000
Security
DHCP features
DHCP client
Access Control List (ACL)
Yes
Access Control List (ACL) ingress
100
IGMP snooping
Yes
Security algorithms
802.1x RADIUS, EAP, HTTPS, SSL/TLS
Loop protection
Yes
Authentication
Auto VLAN, Guest VLAN, MAC-based authentication, Port-based authentication, Web-based authentication
Password protection
Yes
Authentication type
HWTACACS+, IEEE 802.1x
Multicast features
Multicast support
Yes
Number of multicast groups filtered
256
Design
Rack mounting
No
Form factor
Desktop
Product colour
Black
Housing material
Metal
LED indicators
Yes
Number of fans
0 fan(s)
Performance
Built-in processor
Yes
Processor frequency
500 MHz
Memory type
DDR-SDRAM
Internal memory
128 MB
Flash memory
32 MB
Firmware upgradeable
Yes
Power
Power source
DC/PoE
Power over Ethernet (PoE)
Power over Ethernet (PoE)
Yes
Power over Ethernet plus (PoE+) ports quantity
8
Total Power over Ethernet (PoE) budget
55 W
Other features
Warranty period
3 year(s)
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Storage temperature (T-T)
-20 - 70 °C
Operating relative humidity (H-H)
0 - 90%
Storage relative humidity (H-H)
0 - 95%
Operating altitude
0 - 3000 m
Weight & dimensions
Width
236 mm
Depth
101 mm
Height
30 mm
Weight
610 g
Packaging content
Quick start guide
Yes
User guide
Yes
Manual
Yes
Technical details
Shipping (inner) case height
30.9 cm
Shipping (inner) case width
35 cm
Shipping (inner) case length
27.4 cm
Shipping (inner) case net weight
9.49 kg
Products per shipping (inner) case
6 pc(s)
Information
| Part Number: | GS310TP-200EUS |
