Product Details
Introduction
Get networks up and running with plug-and-play unmanaged switches. Set it and forget it, energy-efficient switches are built like tanks and last for decades.
PLUG & PLAY
Simple setup with no software or configuration needed.
FLEXIBLE MOUNTING
Mount on rack, desktop, or wall.
SMALL SIZE, METAL CASE, AND SILENT OPERATION
Durable quality, space saver, and quietness for peace of mind.
STURDY METAL CASE, DESKTOP/RACKMOUNT FORM FACTOR WITH QUIET FANS
Can be placed on desk or on mounted rack and will operate quietly with assured durability.
Management features
Switch type
Unmanaged
Quality of Service (QoS) support
Y
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity
24
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
Network
Networking standards
IEEE 802.1p,IEEE 802.3,IEEE 802.3ab,IEEE 802.3af,IEEE 802.3az,IEEE 802.3i,IEEE 802.3u,IEEE 802.3x
Cable types supported
Cat5
Auto MDI/MDI-X
Y
Auto-sensing
Y
Data transmission
Switching capacity
48 Gbit/s
MAC address table
8000 entries
Latency (1 Gbps)
4.7 µs
Jumbo frames support
Y
Jumbo frames
9216
Packet forwarding rate (1 Gbps)
1448000 pps
Packet buffer memory
0.512 MB
Design
Rack mounting
Y
Product colour
Black
Housing material
Metal
LED indicators
Activity, Link, Power, Speed
Wall mountable
Y
Certification
CE Mark, FCC 15 A, IC A, RCM, CCC, VCCI, KC, CB, CE LVD
Performance
Fanless
Y
Mean time between failures (MTBF)
620798 h
Power
Power supply included
Y
AC input voltage
110 - 240 V
AC input frequency
50/60 Hz
Input current
1 A
Power consumption (max)
11.1 W
Power over Ethernet (PoE)
Power over Ethernet (PoE)
N
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Storage temperature (T-T)
-20 - 70 °C
Operating relative humidity (H-H)
0 - 90%
Storage relative humidity (H-H)
0 - 95%
Operating altitude
0 - 3000 m
Heat dissipation
37.96 BTU/h
Weight & dimensions
Width
252 mm
Depth
180 mm
Height
44 mm
Weight
1.31 kg
Packaging data
Cables included
AC
Manual
Y
Information
| Part Number: | GS324-200EUS |
